Установкa Thermo King LOCO AUZ схема FRAME AND COVERS – 265A9
Обновление от: 4/8/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | FRAME (see 275F2) | 1 | |
| 2 | 98-9213 | COVER - condenser, assembly (see 257F4) | 1 | |
| 3 | 98-9214 | COVER - evaporator, assembly (see 257F3) | 1 | |
| 4 | NSS | COVER - bottom (see 265A0) | 1 | |
| 5 | NSS | BLOWER - section right (see 265B2) | 1 | |
| 6 | NSS | BLOWER - section left (see 265B1) | 1 | |
| 7 | NSS | ELECTRICAL GROMMETS AND BUSHINGS (see 265B3) | 1 |
