Установкa Thermo King LOCO AUZ схема CONDENSER – 257F7
Обновление от: 3/7/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2762 | COIL - condenser | 1 | |
| 55-6994 | SCREW - coil | 6 | ||
| 55-9190 | WASHER - spring | 6 | ||
| 51-167 | FLATWASHER | 6 | ||
| 55-7373 | NUT - captive | 6 | ||
| 2 | 98-9132 | COVER - top | 1 | |
| 3 | 93-349 | LOCK | 1 | |
| 55-2715 | RIVET - lock | A/R | ||
| 4 | 98-9042 | COVER - bottom | 1 | |
| 5 | 61-378 | ELIMINATOR - vibration | 1 | |
| 6 | 61-6167 | TUBE | 1 | |
| 7 | 66-7392 | VALVE - relief, complete | 1 | |
|
10-66-7392 | Предохранительный клапан | 3 480 ₽ |
|
| PP-66-7392 | Предохранительный клапан | 1 730 ₽ |
|
|
| 33-1015 | O-RING | 1 | ||
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 8 | 91-758 | CLAMP - tube | 1 | |
| 55-8316 | SCREW - clamp | 1 | ||
| 55-7170 | LOCKWASHER | 1 | ||
| 55-8216 | FLATWASHER | 1 | ||
| 9 | 99-7246 | STRIP - neoprene, roll of 10m | A/R |
