Установкa Thermo King LB-I схема INSTALLATION COMPONENTS – 79G8
Обновление от: 6/4/02
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-352 | COMPRESSOR (12V) | 1 | |
| 102-353 | COMPRESSOR (24V) | 1 | ||
| 91-934 | DIPSTICK - oil check | 1 | ||
| 2 | 44-6007 | DIODE - solenoid | 1 | |
| 44-3400 | DIODE - only | 1 | ||
| 55-1852 | LOCKWASHER (bronze) | 2 | ||
| 55-401 | FLATWASHER (brass) | 2 | ||
| 55-346 | NUT | 2 | ||
| 3 | 44-4397 | SOLENOID - power (12V) | 1 | |
| 41-3987 | SOLENOID - power (24V) | 1 | ||
| 4 | 44-6146 | BREAKER - circuit (12V, 40 amp) | 1 | |
|
10-44-6146 | Автоматический выключатель, 40A | 2 220 ₽ |
|
| 44-6145 | BREAKER - circuit (24V, 20 amp) | 1 | ||
|
30-44-6145 | Предохранитель 20А | 1 320 ₽ |
|
| 5 | 98-1201 | HOSE - evaporator drain | 2 | |
| 55-6349 | TEE - drain hose | 1 | ||
| 6 | 67-946 | HOSE - suction (20 ft) | 1 | |
| 7 | 66-4851 | HOSE - discharge (17 ft) | 1 | |
| 99-4515 | SHIELD - hoses | 3 | ||
| 55-2154 | CLAMP - hose (refrigerant discharge) | 8 | ||
| 55-3598 | CLAMP - suction hose (refrigeration) | 8 | ||
| 8 | 44-3940 | DIODE - compressor | 1 | |
| 44-5219 | CONNECTOR | 1 | ||
| 99-8676 | BRACKET - diode | 1 | ||
| 9 | 67-944 | HOSE - liquid/defrost (3 ft) | 2 | |
| 10 | 91-1181 | BOLT - unit mounting | 4 | |
| 11 | 61-3467 | THERMOMETER (see 20C6) | 1 | |
|
10-61-3467 | Термометр | 15 250 ₽ |
|
| 99-9871 | BRACKET - thermometer | 1 | ||
| 41-2590 | THERMOMETER - digital LED (F) | 1 | ||
| 44-5234 | SENSOR (10 ft) | 1 | ||
|
10-44-5234 | Сенсор | 14 130 ₽ |
|
| 55-2997 | SCREW - thermometer | 3 | ||
| 55-1266 | FLATWASHER | 3 | ||
| 55-3233 | LOCKWASHER | 3 | ||
| 55-3519 | NUT | 3 | ||
| 12 | 66-4359 | FILTER - suction line | 1 | |
| 55-2365 | HANGER - filter | 2 | ||
| 55-5664 | SCREW - filter | 2 | ||
| 55-411 | FLATWASHER | 4 | ||
| 55-4118 | NUT (stop) | 2 | ||
| 13 | 44-6313 | BOX - cab control (see 63D5) | 1 | |
| 14 | 33-1216 | GROMMET - extrusion | 1 | |
| 15 | 55-3970 | FITTING - hose/swivel (#8 straight) | 1 | |
| 55-2885 | FITTING - hose/swivel (#8 elbow) | 2 | ||
| 55-2884 | FITTING - hose/swivel (#12 straight) | 1 | ||
| 55-5225 | FITTING - hose/swivel (#12 elbow) | 2 | ||
| 16 | 204-677 | CUTTER - hose | 1 | |
| 204-678 | BLADE - replacement | 1 | ||
| 17 | 204-676 | CRIMPER - R12 hose | 1 | |
| 18 | 204-679 | FITTING - charging lines (w/ Schrader valve) | 1 |
