Установкa Thermo King KV-500 MAX схема FITTINGS & HOSES (Codan) – 241C8
Обновление от: 4/8/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 51-1977 | FITTING - 90 degree (#6) | A/R | |
| 51-1978 | FITTING - 90 degree (#8) | A/R | ||
| 51-1973 | FITTING - 90 degree (#12) | A/R | ||
| 2 | 51-1974 | FITTING - straight (#6) | A/R | |
| 51-1975 | FITTING - straight (#8) | A/R | ||
| 51-1976 | FITTING - straight (#10) | A/R | ||
| 3 | 33-1015 | O-RING (0-ring seal, #6 hose) | A/R | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 33-566 | O-RING (0-ring seal, #8 hose) | A/R | ||
| 33-1222 | O-RING (0-ring seal, #12 hose) | A/R | ||
| 4 | 51-1981 | CAGE & CLIP ASSEMBLY (#6) | A/R | |
| 51-1979 | CAGE & CLIP ASSEMBLY (#8) | A/R | ||
| 51-1980 | CAGE & CLIP ASSEMBLY (#12) | A/R | ||
| 5 | 61-4954 | HOSE (#6, 3.5 meters long) | A/R | |
| 61-4959 | HOSE (#8, 4.0 meters long) | A/R | ||
| 61-4953 | HOSE (#12, 5.5 meters long) | A/R | ||
| 6 | 51-1971 | FITTING - 90 degree (#8) | A/R | |
| 51-1972 | FITTING - 90 degree (#12) | A/R | ||
| 7 | 33-2350 | O-RING (tube-o, #8) | A/R | |
| 33-672 | O-RING (tube-o, #10, #12) | A/R | ||
|
10-33-672 | Прокладка компрессора Regulator | 410 ₽ |
|
| 33-672 OEM | Прокладка компрессора Regulator | 80 ₽ |
|
