Установкa Thermo King KV-500 MAX схема POWER RECEPTACLE GROUP (EMEIA) – 231C8
Обновление от: 5/30/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-1948 | BOX - power receptacle | 1 | |
| 55-2979 | SCREW - box | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-5984 | NUT - blind | 2 | ||
| 2 | 92-1949 | COVER - box | 1 | |
| 3 | 41-4664 | BLOCK - terminal (5 pole) | 1 | |
| 4 | 99-7834 | NAMEPLATE - caution | 1 | |
| 5 | 33-3547 | BOOT - rubber | 1 | |
| 6 | 55-9986 | FITTING - barb (3/4 mpt pvc) | 1 | |
| 7 | 41-9190 | CABLE - power | 1 | |
| 8 | 41-4666 | RECEPTACLE - power (220-230/3/50-60, mates w/ 41-782) | 1 | |
| 41-519 | RECEPTACLE - power (380/3/50, mates w/ 41-520) | 1 | ||
| 41-3667 | RECEPTACLE - power (220/1/50, mates w/ 41-972) | 1 | ||
| 9 | 99-9052 | COVER - receptacle | 1 | |
| 10 | 33-1697 | GASKET - receptacle | 1 | |
| 11 | 91-3448 | NAMEPLATE (220V) | 1 | |
| 99-8917 | NAMEPLATE (230V) | 1 | ||
| 99-9700 | NAMEPLATE (380V) | 1 | ||
| 12 | 41-782 | PLUG - power (220-230/3/50-60, mates w/ 41-4666) | 1 | |
| 41-520 | PLUG - power (380/3/50, mates w/ 41-519) | 1 | ||
| 41-972 | PLUG - power (220/1/50, mates w/ 41-3667) | 1 |
