Установкa Thermo King KV-500 MAX схема GRILLE & FAN GROUP – 230F3
Обновление от: 3/1/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 78-1185 | FAN - condenser (12VDC draw) | 2 | |
| 10-78-1375 | Вентилятор конденсатора 12V, V/C-Series | 10 220 ₽ |
|
|
| PP-78-1375 | Вентилятор конденсатора 12V, V/C-Series | 4 870 ₽ |
|
|
| 78-1186 | FAN - condenser (24VDC draw) | 2 | ||
|
10-78-1376 | Вентилятор конденсатора 24V, V-Series | 11 710 ₽ |
|
|
PP-78-1376 | Вентилятор конденсатора 24V, V-Series | 4 530 ₽ |
|
| 55-7407 | SCREW - fan | 8 | ||
| 55-5970 | WASHER - sealing | 8 | ||
| 55-8375 | NUT - captive | 8 | ||
| 2 | 98-8030 | FRAME - condenser (10 & 30 units) | 1 | |
| 98-8016 | FRAME - condenser (20 & 50 units) | 1 | ||
| 3 | 33-4443 | GASKET - vertical | 2 | |
| 4 | 33-4442 | GASKET - horizontal | 2 | |
| 5 | 98-8020 | GRILLE - condenser | 1 | |
| 55-7372 | SCREW - cover | 5 | ||
| 55-5970 | WASHER - sealing | 8 | ||
| 6 | 98-8021 | SCREEN - top | 1 | |
| 55-7372 | SCREW - screen | 6 | ||
| 55-5970 | WASHER - sealing | 6 | ||
| 7 | 92-6866 | COVER - belt | 1 | |
| 8 | 92-6870 | COVER - receiver tank | 1 | |
| 55-6994 | SCREW - cover | 5 | ||
| 55-6995 | FLATWASHER | 5 | ||
| 55-6996 | LOCKWASHER | 5 | ||
| 9 | 33-4341 | INSULATION - foam | 3 | |
| 10 | 92-8107 | SUPPORT - heating (30 & 50) | 1 | |
| 55-5130 | RIVET - support | 3 |
