Установкa Thermo King KV-300 & KV-300 MAX схема HOSE CONNECTIONS (KV-300 MAX) – 217H4
Обновление от: 8/22/06
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 61-3744 | TUBE - evaporator to condenser (suction) | 1 | |
| 2 | 61-3745 | TUBE - condenser to evaporator (liquid) | 1 | |
| 3 | 61-3746 | TUBE - condenser to evaporator (hot gas) | 1 | |
| 4 | 33-2115 | O-RING (5/8 id, #10) | 6 | |
| 5 | 33-1015 | O-RING (3/8 id, #6) | 6 | |
| 33-1015 OEM | О-ринг фильтра-осушителя, 3/8" | 240 ₽ |
|
|
| 6 | 33-566 | O-RING (1/2 id) | 4 | |
| 7 | 33-672 | O-RING (9/16 id) | 2 | |
|
10-33-672 | Прокладка компрессора Regulator | 410 ₽ |
|
| 33-672 OEM | Прокладка компрессора Regulator | 80 ₽ |
|
|
| 8 | 61-3147 | TUBE - hot gas | 1 | |
| 9 | 55-8951 | SHOULDER - o-ring | 1 | |
| 55-8950 | NUT - shoulder | 1 | ||
| 10 | 66-9842 | VALVE (Schrader) | 1 | |
| 11 | 55-6403 | ADAPTER | 1 | |
| 12 | 61-3148 | TUBE - suction | 1 | |
| 13 | 55-6400 | ADAPTER | 1 | |
| 14 | 61-3150 | TUBE - valve to condenser | 1 | |
| 15 | 61-3151 | TUBE - shoulder to valve | 1 | |
| 55-6400 | ADAPTER | 1 | ||
| 16 | 61-3137 | VALVE - check | 1 | |
| 17 | 61-3149 | TUBE - liquid | 1 | |
| 18 | 61-3143 | HOSE - discharge | 1 | |
| 19 | 61-3144 | HOSE - suction | 1 | |
| 20 | 61-3145 | HOSE - suction (A/C) | 1 | |
| 21 | 61-3146 | HOSE - liquid (A/C) | 1 | |
| 22 | 102-875 | COMPRESSOR (12V, TM16-XD less clutch, see 179A7) | 1 | |
| 203-515 | OIL - compressor (1 liter) | A/R | ||
| 23 | N/A | COIL - A/C (not supplied by Thermo King) | 1 | |
| 24 | 92-4718 | HOSE - defrost (evap to connector) | 2 | |
| 25 | 92-4720 | CONNECTOR | 2 | |
| 26 | 92-4719 | HOSE - defrost | 2 |
