Установкa Thermo King KV-200 схема KV-200 REFERENCE SHEET – 15U1
Обновление от: 4/19/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 901299 | System - KV200 MAX 10 & 20 | 12/09 | ||
| 901312 | System - KV200 MAX 30 & 50 | 12/09 | ||
| 085451 | Evaporator - KV200 | 1/10 | ||
| 085452 | Control System 12V, MAX 10 & 20 | 1/10 | ||
| 085453 | Control System 24V, MAX 10 & 20 | 1/10 | ||
| 085454 | Control System 12V, MAX 30 & 50 | 1/10 | ||
| 085455 | Control System 24V, MAX 30 & 50 | 1/10 | ||
| 085481 | Condenser - KV200 MAX 30 & 50 | 1/10 | ||
| 085482 | Condenser - KV200 MAX 10 & 20 | 1/10 | ||
| 700670 | KV200 Standby Kit - 380/3/50 12VDC | 9/09 | ||
| 700671 | KV200 Standby Kit - 380/3/50 24VDC | 9/09 | ||
| 700672 | KV200 Standby Kit - 230/3/60 12VDC | 9/09 | ||
| 700673 | KV200 Standby Kit - 230/3/60 24VDC | 9/09 | ||
| 701246 | Plug & Receptacle 380V | 9/09 | ||
| 701247 | Plug & Receptacle 230V | 9/09 | ||
| 701916 | KV200 Standby Kit - 220V 1PH , 12V | 1/10 | ||
| 701917 | KV200 Standby Kit - 220V 1PH , 24V | 1/10 | ||
| 701972 | Nose Mount Installation Kit | 4/10 | ||
| 701973 | Roof Mount Installation Kit | 1/10 | ||
| 702185 | Nose Mount Installation Kit | 4/10 | ||
| 702186 | Roof Mount Installation Kit | 1/10 | ||
| 719260 | Compressor - TM15-XD VG (12VDC) | 1/10 | ||
| 719261 | Compressor - TM15-XD VG (24VDC) | 1/10 | ||
| 800463 | Plug & Socket Kit 220V/1PH/50HZ | 1/10 |
