Установкa Thermo King KRS схема RETURN AIR GRILLE (700780) – 217A1
Обновление от: 12/7/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-7554 | FRAME - return air grille | 1 | |
| 55-5641 | SCREW - grille | 15 | ||
| 2 | 91-8903 | HINGE - grille | 3 | |
| 55-2270 | RIVET - hinge | 9 | ||
| 3 | 91-7625 | LOCKPLATE | 3 | |
| 4 | 55-2074 | NUT - speed | 3 | |
| 55-3035 | RIVET - plate | 6 | ||
| 5 | 91-9639 | ANGLE | 2 | |
| 55-2012 | RIVET - screen & angle | 15 | ||
| 6 | 92-5814 | SCREEN | 1 | |
| 7 | 91-7101 | BODY - latch | 2 | |
| 8 | 92-5815 | FILTER - air | 1 | |
| 9 | 55-9283 | SCREW - lock | 3 | |
| 10 | 55-7112 | WASHER - special (0.255 id) | 3 | |
| 11 | 91-9638 | NAMEPLATE - Thermo King | 1 |
