Установкa Thermo King KD-II & KD-II MAX схема PRESSURE DIFFERENTIAL – 117E6
Обновление от: 2/5/96
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 66-2020 | SWITCH - air pressure differential | 1 | |
|
P-12-01039-08 | Выключатель размораживания, Maxima/Supra/ Vector 1350/1550/18XX/19XX | 16 490 ₽ |
|
| 2 | 55-4560 | NUT | 2 | |
| 55-2001 | FLATWASHER | 2 | ||
| 3 | 91-503 | BRACKET - pressure differential switch | 1 | |
| 4 | 55-1587 | SCREW - bracket | 2 | |
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 5 | 99-1142 | HOSE (clear, 25 ft) | A/R | |
| 6 | 99-1143 | HOSE (black, 25 ft) | A/R | |
| 7 | 99-1275 | PROBE - air switch | 2 | |
| 10-99-1275 | Зонд | 800 ₽ |
|
|
| 55-3136 | RIVET - probe | 2 |
