Установкa Thermo King JD-II схема CONTROL PANEL – 111E1
Обновление от: 6/4/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-4817 | PANEL - bracket | 1 | |
| 55-3015 | SCREW - cover | 4 | ||
| 55-3008 | WASHER - sealing | 4 | ||
| 2 | 99-4976 | STRIP - gasket (50 ft) | A/R | |
| 3 | 44-8464 | BOARD - Cycle Sentry switch | 1 | |
| 4 | 91-4390 | NAMEPLATE - panel (50 std) | 1 | |
| 91-4392 | NAMEPLATE - panel (30 std) | 1 | ||
| 91-4391 | NAMEPLATE - 30 Cycle Sentry | 1 | ||
| 91-4389 | NAMEPLATE - panel (50 Cycle Sentry) | 1 | ||
| 5 | 45-1579 | THERMOSTAT | 1 | |
| 92-6219 | FACEPLATE - TG V (includes 91-4642 overlay) | 1 | ||
| 91-4642 | OVERLAY - TG V (transparent) | 1 | ||
| 33-2128 | GASKET | 1 | ||
| 44-5234 | SENSOR - thermostat | 1 | ||
|
10-44-5234 | Сенсор | 14 130 ₽ |
|
| 55-3443 | SCREW - thermostat | 4 | ||
| 55-2202 | LOCKWASHER | 4 | ||
| 6 | 44-8687 | BUTTON - reset | 1 | |
| 7 | 44-9003 | BOARD - switch (see 88E10) | 1 | |
| 8 | 44-7774 | BREAKER - circuit | 1 | |
|
10-44-7774 | Тепловой предохранитель, SB-I/II/III / SMX | 12 430 ₽ |
|
| 44-8688 | BOOT | 1 | ||
| 55-4396 | SCREW - terminals | 4 | ||
| 9 | 44-9333 | BOARD - relay (see 111D12) | 1 | |
| 55-7556 | STANDOFF - pc board | 4 | ||
| 55-2989 | SCREW - board | 4 | ||
| 55-2201 | FLATWASHER | 4 | ||
| 55-2202 | LOCKWASHER | 4 |
