Установкa Thermo King IRV-HVAC System (ISAP A & B) схема HEATER – 219H5
Обновление от: 5/23/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 45-2237 | HEATER | 1 | |
| 55-6994 | SCREW - heater | 7 | ||
| 55-6996 | LOCKWASHER | 7 | ||
| 55-8893 | FLATWASHER | 7 | ||
| 55-7373 | NUT - captive | 7 | ||
| 2 | 55-9710 | BUSHING - cable | 1 | |
| 55-9711 | LOCKNUT - bushing | 1 | ||
| 3 | 41-4586 | SWITCH - temperature (90 deg C) | 1 | |
| 4 | 41-5937 | SWITCH - temperature (70 deg C) | 2 | |
| 55-9195 | SCREW - switch | 6 | ||
| 55-7750 | LOCKWASHER | 6 | ||
| 5 | 99-3281 | MOUNT - bandwrap | 4 | |
| 55-5130 | RIVET - mount | 4 | ||
| 55-2330 | BANDWRAP | 4 | ||
| 6 | 33-3972 | INSULATION | 1 |
