Установкa Thermo King Hydraulic Drive QS616B схема COMPRESSOR – 234G0
Обновление от: 3/17/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 102-954 | COMPRESSOR (see 244A3) | 1 | |
| 51-1841 | SCREW - compressor | 6 | ||
| 108-2348 | BOLT | 1 | ||
| 108-1746 | FLATWASHER | 1 | ||
| 2 | 92-7703 | FLANGE | 1 | |
| 3 | 66-5492 | VALVE - service, discharge | 1 | |
| 55-9727 | SCREW - valve | 2 | ||
| 55-4625 | FLATWASHER | 2 | ||
| 4 | 33-230 | O-RING (1.875 id) | 1 | |
|
10-33-230 | О-ринг сервисного клапана, X418/426/430/640 | 380 ₽ |
|
| PP-33-230 | О-ринг сервисного клапана, X418/426/430/640 | 220 ₽ |
|
|
| 5 | 51-361 | FITTING - high-side | 1 | |
| 6 | 22-1171 | SPACER - suction | 1 | |
| 55-9726 | SCREW - spacer | 2 | ||
| 55-7024 | FLATWASHER | 2 | ||
| 7 | 33-3707 | O-RING | 1 | |
| 8 | 55-3364 | PLUG | 1 | |
| 9 | 61-1977 | VALVE - suction | 1 | |
| 55-7414 | SCREW - valve | 4 | ||
| 55-5914 | FLATWASHER | 4 | ||
| 10 | 33-3708 | O-RING | 1 | |
| 11 | 55-466 | ELBOW | 1 | |
| 12 | 51-360 | FITTING - low-side | 1 | |
| 13 | 41-3827 | SENSOR | 1 | |
| 14 | 33-3381 | O-RING | 1 | |
| 15 | 55-9730 | ADAPTER | 1 | |
| 16 | 41-8865 | SWITCH - hpco | 1 | |
| 17 | 41-5213 | COIL - 24VDC | 2 | |
| 44-5838 | CONNECTOR - tower (2-pin) | 2 | ||
| 44-5885 | SEAL - cable (green, 18-22 ga) | 4 | ||
| 44-5884 | TERMINAL - female (18-20 ga) | 4 | ||
| 18 | 99-9084 | NAMEPLATE - Arrow | 1 | |
| 19 | 91-3247 | NAMEPLATE - TK logo | 1 | |
| 20 | 91-5459 | NAMEPLATE - R134a | 1 | |
| 56-2330 | BANDWRAP (1.75 dia) | A/R | ||
| 56-2331 | BANDWRAP (4.0 dia) | A/R | ||
| 21 | 55-9032 | KEY | 1 | |
|
10-55-9032 | Шпонка коленвала, X426LS/430LS | 590 ₽ |
|
