Установкa Thermo King Heater PLUTO схема MODULE ASSEMBLY (1E08249G01) – 194F6
Обновление от: 6/1/04
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-3974 | COVER | 1 | |
| 2 | 92-3975 | PLATE - side 1 | 1 | |
| 55-2715 | RIVET - plate | 2 | ||
| 3 | 92-3976 | PLATE - side 2 | 1 | |
| 55-2715 | RIVET - plate | 2 | ||
| 4 | 92-3977 | PLATE | 1 | |
| 5 | 92-3978 | BRACKET - fan | 1 | |
| 55-7826 | SCREW (M5) | 4 | ||
| 55-7404 | LOCKWASHER (M5) | 4 | ||
| 55-7033 | FLATWASHER (M5) | 4 | ||
| 6 | 33-367 | GROMMET (0.125 id) | 2 | |
| 7 | 33-3838 | GROMMET (0.625 id) | 2 | |
| 8 | 67-2017 | COIL | 1 | |
| 55-2715 | RIVET - coil | 4 | ||
| 9 | 78-1413 | FAN (24VDC) | 1 | |
| 51-902 | SCREW (M4) | 4 | ||
| 55-7369 | LOCKWASHER (M4) | 4 | ||
| 55-7368 | FLATWASHER (M4) | 4 |
