Установкa Thermo King HRT-II W Split R134a схема CONDENSER FRAME & INSULATION – 175B7
Обновление от: 7/6/04
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 33-314 | GROMMET (5/16 id) | 2 | |
| 2 | 55-3458 | PIN - cotter | 2 | |
| 3 | 55-7825 | NUT | 12 | |
| 4 | 92-2007 | STRIP | 2 | |
| 5 | 92-2008 | STRIP | 2 | |
| 6 | 92-2096 | PANEL - front | 1 | |
| 55-7373 | NUT - captive | 1 | ||
| 7 | 92-2097 | PANEL - middle | 1 | |
| 55-7373 | NUT - captive | 1 | ||
| 8 | 92-2098 | PANEL - back | 1 | |
| 55-7373 | NUT - captive | 1 | ||
| 9 | 91-9883 | STRIP | 4 | |
| 10 | 92-2009 | STRIP | 4 | |
| 11 | 91-9880 | STRIP | 6 | |
| 12 | 91-7386 | CLAMP - rod | 2 | |
| 55-7368 | FLATWASHER | 2 | ||
| 55-5047 | RIVET | 2 | ||
| 13 | 92-1163 | ROD - cover | 2 | |
| 14 | 98-5628 | PLATE - bottom | 1 | |
| 15 | 91-9881 | HOLDER | 2 | |
| 16 | 98-6380 | PLATE - bottom | 1 | |
| 17 | 55-6995 | FLATWASHER | 2 | |
| 18 | 55-7075 | FLATWASHER | 12 | |
| 19 | 55-7085 | FLATWASHER | 24 | |
| 20 | 55-7170 | LOCKWASHER | 12 | |
| 21 | 55-7342 | LOCKWASHER | 12 | |
| 22 | 55-6994 | SCREW - frame to coil | 12 | |
| 23 | 55-7341 | SCREW - panel to coil | 12 | |
| 24 | 98-6381 | FRAME - condenser (roadside) | 1 | |
| 25 | 98-6382 | FRAME - condenser (curbside) | 1 | |
| 26 | 67-1841 | COIL - condenser (curbside, see 175B8) | 1 | |
| 27 | 67-1825 | COIL - condenser (roadside, see 175B8) | 1 |
