Установкa Thermo King HRT-I W 1012 COBUS 3000 схема HARNESS GROUP – 171F8
Обновление от: 11/27/01
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | PANEL - control | 1 | |
| 2 | 41-4569 | SWITCH - driver panel | 1 | |
| 3 | 41-1932 | FUSE (1 amp) | 1 | |
| 4 | 41-4570 | HARNESS - control panel to evap (rear) | 1 | |
| 5 | 41-4571 | HARNESS - control panel to evap (front) | 1 | |
| 41-280 | TERMINAL - fork (12-10, #10, yellow) | A/R | ||
| 44-5066 | TERMINAL - fingrip (14-18 ga) | A/R | ||
| 6 | 41-4572 | HARNESS - control panel to powerpack | 1 | |
| 41-438 | TERMINAL - fork (22-16, #6) | A/R | ||
| 7 | 41-4573 | HARNESS - control panel to condenser | 1 | |
| 44-5087 | TERMINAL - fork (yellow #10, 10-12 ga) | A/R | ||
| 8 | 41-4574 | HARNESS - control panel to driver panel | 1 | |
| 44-1031 | TERMINAL - ring (16-22, 5/16, red) | A/R | ||
| 9 | 55-5919 | CONNECTOR - harness grip | 2 | |
| 10 | 41-4575 | SWITCH - door | 1 | |
| 11 | 41-4576 | FUSE (150 amp) | 1 | |
| 44-8708 | HOLDER - fuse | 1 | ||
| 41-226 | FUSE (40 amp) | 1 | ||
|
10-41-226 | Предохранитель 40 ампер 10 шт | 1 860 ₽ |
|
| 12 | 41-3021 | ALTERNATOR (24V, see 67D13) | 1 | |
| US-41-3021 | Генератор 150 А | 141 810 ₽ |
|
|
| 10-41-3021 | Генератор 24В, 150А | 92 860 ₽ |
|
|
| 13 | 91-9006 | HOSE - evaporator drain | ||
| 55-6726 | CLAMP - hose | 4 |
