Установкa Thermo King HK & HK-II SERIES схема ENGINE MOUNTING (HK-II) – 104B3
Обновление от: 3/26/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 11-6666 | HOUSING - flywheel | 1 | |
| 2 | 55-529 | SCREW - housing | 3 | |
| 55-402 | FLATWASHER | 6 | ||
| 55-375 | LOCKWASHER | 3 | ||
| 55-289 | NUT | 3 | ||
| 99-8032 | NUTSTRIP - housing | 2 | ||
| 55-2988 | RIVET - nutstrip | 2 | ||
| 55-2252 | SCREW | 2 | ||
| 3 | 41-2195 | ALTERNATOR (37 amp, model EA, see 78A9, model 8MR) | 1 | |
|
10-41-2195 | Генератор 37A, MD/RD/TD-II / SB-II/III | 19 510 ₽ |
|
| 4 | 78-1103 | BELT - alternator | 1 | |
| 5 | 55-5410 | SCREW - alternator | 1 | |
| 55-2038 | FLATWASHER | 2 | ||
| 55-365 | LOCKWASHER | 1 | ||
| 55-287 | NUT | 1 | ||
| 6 | 55-2969 | SCREW - alternator adjusting | 1 | |
| 55-790 | LOCKWASHER | 1 | ||
| 55-2769 | WASHER - special | 1 | ||
| 7 | 55-5772 | SCREW - adjust arm | 1 | |
| 8 | 99-9768 | BRACKET - alternator adjusting arm | 1 | |
| 9 | 99-9767 | BRACKET - engine & alternator (HK-I) | 1 | |
| 91-3493 | BRACKET - engine & alternator (HK-II) | 1 | ||
| 10 | 55-6216 | SCREW - bracket | 8 | |
| 55-364 | LOCKWASHER | 8 | ||
| 55-5620 | LOCKWASHER | 8 | ||
| 11 | 99-9766 | BRACKET - engine (HK-I) | 1 | |
| 91-3494 | BRACKET - engine (HK-II) | 1 | ||
| 12 | 55-2747 | SCREW - bracket to frame | 4 | |
| 55-6168 | WASHER - special | 4 | ||
| 55-2173 | FLATWASHER | 4 | ||
| 55-4952 | NUT | 4 | ||
| 13 | 33-2528 | GASKET - flywheel housing | 1 | |
| 14 | 77-1809 | ADAPTER - engine to blower | 1 | |
| 55-5427 | SCREW - adapter | 6 | ||
| 15 | 77-1806 | ADAPTER - blower | 1 | |
| 16 | 78-1138 | BLOWER | 1 | |
| 55-5166 | SCREW - blower | 8 | ||
| 55-6167 | LOCKWASHER | 8 | ||
| 17 | 77-1805 | BUSHING | 1 | |
| 18 | 70-150 | KIT - blower | 1 | |
| 19 | 77-2584 | SHAFT - coupling | 1 | |
| 20 | 55-6029 | WASHER - special | 1 | |
| 21 | 78-840 | COUPLING - engine | 1 | |
| 22 | 55-5022 | SCREW - coupling | 6 | |
| 55-371 | FLATWASHER | 6 | ||
| 23 | 55-411 | FLATWASHER | 8 | |
| 24 | 55-6166 | SCREW - blower | 8 | |
| 25 | 55-366 | LOCKWASHER | 8 | |
| 26 | 78-1138 | BLOWER | 1 |
