Установкa Thermo King HK-430 & HK-430 HO схема COOLING SYSTEM (HK-430 HO) – 256A7
Обновление от: 4/14/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 13-418 | HOUSING - thermostat (see 214B1) | 1 | |
| 2 | 55-3401 | CLAMP - hose (EDPM) | 8 | |
| 51-1739 | CLAMP - hose (silicone) | 8 | ||
| 3 | 13-1155 | HOSE - muffler to radiator (EDPM) | 1 | |
| 13-1156 | HOSE - muffler to radiator (silicone) | 1 | ||
| 4 | 12-965 | COIL - radiator | 1 | |
| 55-6993 | SCREW - coil | 6 | ||
| 55-7342 | LOCKWASHER | 6 | ||
| 55-7085 | FLATWASHER | 6 | ||
| 5 | 66-2672 | ADAPTER | 1 | |
| 6 | 55-7134 | COCK - drain | 1 | |
| 7 | 13-1142 | HOSE - radiator to tee (EDPM) | 1 | |
| 13-1143 | HOSE - radiator to tee (silicone) | 1 | ||
| 8 | 13-746 | HOSE - tee to engine (EDPM) | 1 | |
| 13-1144 | HOSE - tee to engine (silicone) | 1 | ||
| 9 | 13-1145 | TEE - tube (radiator to engine) | 1 | |
| 10 | 13-1146 | HOSE - tee to tank (EDPM) | 1 | |
| 13-1147 | HOSE - tee to tank (silicone) | 1 | ||
| 11 | 13-1148 | CLAMP - hose (EDPM hose) | 3 | |
| 55-1521 | CLAMP - hose (silicone hose) | 3 | ||
| 12 | 13-1057 | TANK - expansion | 1 | |
|
10-13-1057 | Расширительный бачок, T-Series | 17 820 ₽ |
|
| 13 | 13-990 | CAP - radiator (15 psi) | 1 | |
|
10-13-990 | Крышка расширительного бачка, T-Series | 1 490 ₽ |
|
| 14 | 13-957 | CAP - overflow tank | 1 | |
| 15 | 42-427 | SWITCH - coolant level | 1 | |
| 16 | 33-3007 | O-RING | 1 | |
| 33-3007 OEM | О-ринг сервисного клапана, X426/430/640 | 130 ₽ |
|
|
| 51-718 | SCREW - tank | 4 | ||
| 17 | 92-9236 | BRACKET - expansion tank | 1 | |
| 55-2969 | SCREW - bracket | 4 | ||
| 55-790 | LOCKWASHER | 4 | ||
| 55-371 | FLATWASHER | 4 | ||
| 18 | 13-1157 | HOSE - muffler vent (EDPM) | 1 | |
| 13-1158 | HOSE - muffler vent (silicone) | 1 | ||
| 19 | 51-2149 | CLAMP - hose (EDPM) | 3 | |
| 55-6731 | CLAMP - hose (silicone) | 3 | ||
| 20 | 13-1159 | HOSE - engine to muffler (EDPM) | 1 | |
| 13-1160 | HOSE - engine to muffler (silicone) | 1 | ||
| 21 | 51-1336 | TEE | 1 | |
| 22 | 55-2539 | BUSHING | 1 | |
| 23 | 51-2158 | ELBOW - hose | 2 | |
| 24 | 51-2159 | NIPPLE | 1 | |
| 25 | 12-905 | MUFFLER (see 213E2) | 1 | |
| 26 | 55-6156 | CLAMP - hose | 1 | |
| 27 | 41-6538 | SWITCH - coolant temperature | 1 | |
|
10-41-6538 | Сенсор температуры двигателя, SLX/SB-XXX | 18 500 ₽ |
|
|
PP-41-6538 | Сенсор температуры двигателя, SLX/SB-XXX | 3 210 ₽ |
|
| 28 | 33-572 | GROMMET - hose | 1 | |
| 29 | 12-538 | HOSE - muffler vent (cut to 9 inches) | A/R | |
| 30 | 55-3364 | PLUG | 1 | |
| 31 | 98-771 | HOSE - overflow | 1 | |
| 32 | 55-6147 | CLAMP - hose | 4 |
