Установкa Thermo King HK-430 & HK-430 HO схема CONTROL BOX – 256A3
Обновление от: 10/2/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8801 | PANEL - curbside (control box, see 256A6) | 1 | |
| 2 | 55-6476 | STANDOFF - self clinch | 8 | |
| 3 | 33-4822 | GASKET - control box (horizontal) | 2 | |
| 4 | 33-4823 | GASKET - control box (vertical) | 2 | |
| 5 | 92-9242 | PANEL - control box (top) | 1 | |
| 6 | 92-9243 | PANEL - control box (bottom) | 1 | |
| 55-4560 | NUT - control box | 8 | ||
| 55-2001 | FLATWASHER | 6 | ||
| 55-3136 | RIVET - panel | 8 | ||
| 7 | 33-1371 | GROMMET | 1 | |
| 8 | 99-6093 | MOUNT - bandwrap | 2 | |
| 55-3136 | RIVET - mount | 2 | ||
| 9 | 45-2391 | BOARD - control | 1 | |
| 55-3020 | SCREW - board | 9 | ||
| 55-2964 | LOCKWASHER | 9 | ||
| 51-2157 | FLATWASHER (nylon) | 9 | ||
| 10 | 41-1771 | FUSE - 30 amp | 1 | |
| 30-41-1771 | Предохранитель 32V 30А | 460 ₽ |
|
|
| 11 | 92-9244 | COVER - control box | 1 | |
| 12 | 99-7246 | GASKET - control box | A/R | |
| 55-7734 | SCREW - cover | 2 | ||
| 55-8667 | STANDOFF - screw | 2 | ||
| 55-7774 | SPRING - screw | 2 | ||
| 55-7734 | RETAINER | 2 |
