Установкa Thermo King Front Box MILLEN 600455 схема EVAPORATOR – 257E1
Обновление от: 6/29/12
| № | TK # | Описание | Кол-во Цена |
|---|---|---|---|
| 1 | 67-1888 | EVAPORATOR | 1 |
| 2 | 61-2546 | VALVE - thermostatic expansion | 1 |
| 51-257 | RIVET - evaporator | A/R | |
| 3 | 61-2497 | ADAPTER | 1 |
| 4 | 61-6093 | TUBE | 1 |
| 5 | 92-121 | NUT | 1 |
| 6 | 55-9544 | ADAPTER | 1 |
| 7 | 33-1461 | O-RING | 1 |
| 8 | 41-6348 | VALVE - solenoid | 1 |
| 51-134 | SCREW - valve | 2 | |
| 55-7031 | LOCKWASHER - valve | 2 | |
| 9 | 41-4157 | SENSOR - temperature | 3 |
| 10 | 99-5966 | STRIP - neoprene | A/R |
