Установкa Thermo King Front Box MILLEN 600455 схема HEATER – 257D0
Обновление от: 6/29/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 12-857 | HEATER | 1 | |
| 51-257 | RIVET - heater | 8 | ||
| 2 | 92-5032 | HOSE - silicone | A/R | |
| 3 | 55-3401 | CLAMP - tube | 4 | |
| 4 | 41-5649 | VALVE - water | 1 | |
| 55-7802 | SCREW - valve | 1 | ||
| 55-4638 | FLATWASHER - valve | 1 | ||
| 55-7007 | NUT - valve | 1 | ||
| 5 | 41-4157 | SENSOR - temperature | 1 | |
| 6 | 99-5966 | STRIP - neoprene | A/R |
