Установкa Thermo King F-2L to F-5L & Cool Station Eutectic схема CONTROL PANEL (3 PHASE) – 167B2
Обновление от: 3/23/11
| № | TK # | Описание | Кол-во Цена |
|---|---|---|---|
| 1 | 92-1310 | PANEL - components (3 phase) | 1 |
| 2 | 41-1036 | TRANSFORMER (90VA 220V 50 Hz output) | 1 |
| 41-4210 | TRANSFORMER (90VA 230V 60 Hz output) | 1 | |
| 55-9348 | SCREW - transformer | 4 | |
| 55-7861 | LOCKWASHER | 4 | |
| 3 | 41-3090 | RELAY - overload (2.5 to 4.1A) | 1 |
| 4 | 41-3091 | RELAY - overload (10 to 16A) | 1 |
| 41-3097 | RELAY - overload (4 to 6.3A) | 1 | |
| 5 | 41-3099 | SOCKET - relay overload | 2 |
| 55-7663 | SCREW - socket | 2 | |
| 55-7697 | FLATWASHER | 6 | |
| 6 | 91-9993 | RAIL - din (75 mm) | 1 |
| 55-8290 | RIVET - rail | 3 | |
| 7 | 41-3452 | CONTACTOR (220/3/60) | 1 |
| 41-3454 | CONTACTOR (230/3/60) | 1 | |
| 41-3455 | CONTACTOR (230/3/60) | 1 | |
| 8 | 41-898 | BLOCK - fitting | 2 |
| 9 | 41-3722 | CONNECTOR | 2 |
| 10 | 41-942 | TERMINAL - fuse | 1 |
| 11 | 41-3723 | FUSE (0.5 amp, 250V) | 1 |
| 12 | 41-944 | COVER - connector | 1 |
| 13 | 92-1311 | COVER - control box | 1 |
| 91-9989 | TAPE - sealant | 1 | |
| 14 | 41-3728 | SOCKET - light | 2 |
| 15 | 41-3877 | BULB - light (230V/2W) | 2 |
| 16 | 41-3724 | LIGHT - pilot (green) | 1 |
| 17 | 41-3725 | LIGHT - pilot (red) | 1 |
| 18 | 91-6325 | BUTTON - reset | 2 |
| 91-6324 | ROD - reset | 2 | |
| 19 | 41-4148 | SWITCH - on/off | 1 |
| 20 | 41-4211 | HARNESS - condenser | 1 |
| 21 | 41-4212 | RECEPTACLE (3 ph) | 1 |
| 55-7088 | SCREW - receptacle | 4 | |
| 55-7089 | FLATWASHER | 4 | |
| 55-7404 | LOCKWASHER | 4 | |
| 55-7367 | NUT | 4 |
