Установкa Thermo King EMS-ST24 схема RELAY GROUP – 233G5
Обновление от: 12/7/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 651-285 | DIN RAIL ASSY ST-24 SERIES | 1 | ||
| 1 | 651-177 | DIN RAIL, ST-24 & C-BOX | 1 | |
| 2 | 651-178 | CLAMP - end | 2 | |
| 3 | 651-221 | TERMINAL - block | 6 | |
| 4 | 651-126 | BLOCK - fuse | 2 | |
| 5 | 651-128 | FUSE (1 amp) | 1 | |
| 6 | 651-182 | FUSE (1.5 amp) | 1 | |
| 7 | 651-123 | BASE - relay | 2 | |
| 8 | 651-180 | RELAY (10 amp, 12 v) | 2 | |
| 9 | 651-181 | SUPPLY - power | 1 |
