Установкa Thermo King EMS-3300 схема SUBPANEL ASSEMBLY – 235D4
Обновление от: 10/14/09
| № | TK # | Описание | Кол-во Цена |
|---|---|---|---|
| 1 | 651-228 | SUBPANEL, EMS-3300 | 1 |
| 55-2958 | FLATWASHER | 6 | |
| 51-1182 | LOCKWASHER | 6 | |
| 55-2114 | NUT | 6 | |
| 2 | NSS | RAIL - din (# 2 assembly, see 235D5) | 1 |
| 55-3443 | SCREW | 2 | |
| 55-2201 | FLATWASHER | 2 | |
| 51-1399 | LOCKWASHER | 2 | |
| 3 | NSS | RAIL - din (# 1 assembly, see 235D5) | 1 |
| 55-3443 | SCREW | 2 | |
| 55-2201 | FLATWASHER | 2 | |
| 51-1399 | LOCKWASHER | 2 | |
| 4 | 651-134 | BOARD - CPA | 1 |
| 651-143 | SCREW | 8 | |
| 651-136 | SPACER - nylon | 8 | |
| 651-140 | FLATWASHER | 8 | |
| 55-2993 | LOCKWASHER | 8 | |
| 55-2361 | NUT | 8 | |
| 5 | 651-133 | BOARD - RDOC | 4 |
| 651-143 | SCREW | 8 | |
| 651-136 | SPACER - nylon | 8 | |
| 651-140 | FLATWASHER | 8 | |
| 55-2993 | LOCKWASHER | 8 | |
| 55-2361 | NUT | 8 | |
| 6 | 651-108 | SUPPLY - power (assembly) | 8 |
| 651-110 | SUPPLY - power | 8 | |
| 651-298 | NIPPLE | 8 | |
| 55-5083 | SCREW | 32 | |
| 651-137 | SPACER - nylon | 32 | |
| 651-299 | FLATWASHER | 32 | |
| 55-2998 | LOCKWASHER | 32 | |
| 55-5754 | NUT | 32 | |
| 7 | 651-135 | BRACKET - ground | 2 |
| 55-3003 | SCREW - bracket | 4 | |
| 55-3000 | SCREW - stud | 2 | |
| 55-2996 | LOCKWASHER | 8 | |
| 55-2001 | FLATWASHER | 6 | |
| 55-2965 | NUT | 4 | |
| 651-111 | HARNESS - ET100 | 1 | |
| 44-9589 | RECEPTACLE (2-pin, see 112D9) | 1 | |
| 44-9590 | WEDGE (see 112D9) | 1 | |
| 41-4850 | TERMINAL | 2 | |
| 41-4409 | TERMINAL - ring (red, 8 22-16 ga) | 1 | |
| 44-7245 | TERMINAL - ring (red, 10 22-16 ga) | 1 |
