Установкa Thermo King E-Series Cargo Heater схема FUEL SYSTEM – 221H5
Обновление от: 1/21/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 81-436 | HOSE - exhaust | 1 | |
| 2 | 85-320 | CLAMP - hose | 1 | |
| 3 | 91-7234 | U-BOLT | 2 | |
| 55-2086 | FLATWASHER | 4 | ||
| 55-4953 | NUT | 4 | ||
| 4 | 92-6235 | SHIELD - exhaust | 1 | |
| 5 | 51-1236 | CLAMP - hose (9 mm) | 4 | |
| 6 | 13-481 | HOSE - fuel (connector, 3.5 mm) | 1 | |
| 7 | 81-541 | HOSE - fuel (clear, 2 mm) | 1 | |
| 8 | 81-568 | HOSE - fuel (tank to pump, 5 mm) | 1 | |
| 9 | 51-1235 | CLAMP - hose (11 mm) | 2 | |
| 10 | 84-975 | PUMP - fuel | 1 | |
| 11 | 85-270 | CLAMP - fuel pump | 1 | |
| 12 | 92-6234 | COVER - fuel pump | 1 | |
| 55-5046 | SCREW - cover | 10 | ||
| 13 | 33-1211 | GROMMET | 2 | |
| 14 | 81-451 | PICKUP - fuel | 1 | |
| 81-537 | PICKUP - fuel (16 in) | 1 | ||
| 15 | 85-292 | FITTING - compression (1/2 npt) | 1 |
