Установкa Thermo King Double Deck Hybrid Northern SPECS R134A LOW RA схема INSTALLATION COMPONENTS – 265C5
Обновление от: 3/15/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 56-2330 | BANDWRAP | A/R | |
| 2 | 56-2331 | BANDWRAP | 17 | |
| 3 | 55-9704 | CLIP - self-locking | A/R | |
| 4 | 98-7180 | CHANNEL - side | 2 | |
| 55-9698 | NUT - captive | 8 | ||
| 5 | 92-4953 | BRACKET - support | 2 | |
| 6 | 92-4954 | DUCK - extension | 2 | |
| 7 | 51-749 | SCREW | 4 | |
| 8 | 55-7035 | SCREW | 8 | |
| 9 | 98-8372 | BRACKET - support, curbside | 1 | |
| 10 | 98-8371 | BRACKET - support, roadside | 1 | |
| 11 | 55-7170 | LOCKWASHER | 8 | |
| 12 | 55-7075 | FLATWASHER | 8 | |
| 13 | 51-1956 | WASHER | 8 | |
| 14 | 51-1952 | WASHER | 2 | |
| 15 | 51-1955 | WASHER | 4 | |
| 16 | 51-1954 | WASHER | 4 | |
| 17 | 51-1953 | WASHER | 4 |
