Установкa Thermo King Double Deck Hybrid Northern SPECS R134A LOW RA схема BLOWERS KIT – 203C1
Обновление от: 3/15/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-7175 | FRAME - weldment | 1 | |
| 55-2957 | SCREW - frame | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-6958 | FLATWASHER | 2 | ||
| 55-8711 | NUT - captive | 2 | ||
| 55-2957 | SCREW - frame | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-4414 | FLATWASHER - special | 2 | ||
| 55-8979 | NUT - captive | 12 | ||
| 2 | NSS | BLOWER - assy, left (see 202H9) | 2 | |
| 3 | NSS | BLOWER - assy, right (see 202H9) | 2 | |
| 55-2969 | SCREW - motor to frame | 16 | ||
| 305-1440 | FLATWASHER - special | 8 | ||
| 55-4954 | NUT | 8 | ||
| 55-3834 | SCREW - motor to mount plate | 4 | ||
| 55-2958 | FLATWASHER | 8 | ||
| 55-4954 | NUT | 8 | ||
| 55-1587 | SCREW - housing to bracket | 8 | ||
| 55-1800 | LOCKWASHER | 8 | ||
| 55-6958 | FLATWASHER | 8 | ||
| 55-8711 | NUT - captive | 8 | ||
| 55-2979 | SCREW - housing to evaporator frame | 6 | ||
| 55-1800 | LOCKWASHER | 6 | ||
| 55-6958 | FLATWASHER | 6 | ||
| 55-8711 | NUT - captive | 6 | ||
| 4 | 92-4919 | SPACER | 6 | |
| 5 | 92-4920 | BRACKET - motor drive | 2 | |
| 55-2957 | SCREW - bracket to frame | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 55-6958 | FLATWASHER | 4 | ||
| 55-8979 | NUT - captive | 4 | ||
| 6 | 92-4921 | PLATE - controller | 1 | |
| 55-2957 | SCREW - plate to frame | 3 | ||
| 55-1800 | LOCKWASHER | 3 | ||
| 55-6958 | FLATWASHER | 3 | ||
| 55-8979 | NUT - captive | 3 | ||
| 7 | 92-4922 | BRACKET - blower | 4 | |
| 55-2957 | SCREW - bracket to frame | 8 | ||
| 55-1800 | LOCKWASHER | 8 | ||
| 55-6958 | FLATWASHER | 8 | ||
| 55-8711 | NUT - captive | 8 | ||
| 55-2864 | RIVET - bolt to frame | 8 | ||
| 8 | 92-4923 | PLATE - mount | 2 | |
| 9 | 99-5105 | BOLT- strip | 8 | |
| 305-1440 | FLATWASHER - special | 8 | ||
| 55-4954 | NUT | 8 | ||
| 10 | 55-9721 | CLAMP (0.875 dia) | 2 | |
| 55-2957 | SCREW - clamp to controller plate | 1 | ||
| 55-6958 | FLATWASHER | 2 | ||
| 55-4953 | NUT | 1 | ||
| 11 | 55-9722 | CLAMP (1.125 id) | 1 | |
| 12 | 55-9702 | CLAMP (0.625 id) | 1 | |
| 13 | 44-5555 | BOARD | 1 | |
| 51-1197 | SCREW - board | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 14 | 33-2420 | STRIP - neoprene | A/R | |
| 15 | 92-4961 | INSULATION | 1 | |
| 16 | 92-4962 | INSULATION | 1 | |
| 17 | 92-4963 | INSULATION | 1 | |
| 18 | 92-4964 | INSULATION | 1 | |
| 19 | 92-4928 | INSULATION | 1 | |
| 20 | 92-4965 | INSULATION | 1 | |
| 21 | 92-4966 | INSULATION | 1 |
