Установкa Thermo King D5-M7 схема EVAPORATOR REFRIGERATION COMPONENTS – 236G1
Обновление от: 7/20/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 67-2258 | COIL - evaporator | 1 | |
| 55-8711 | INSERT - coil | 14 | ||
| 2 | 92-4646 | PLATE - bolt | 2 | |
| 55-4414 | WASHER - spl (0.281 id) | 4 | ||
| 55-4953 | NUT - lock | 4 | ||
| 3 | 55-2957 | SCREW - coil | 5 | |
| 4 | 55-1800 | LOCKWASHER | 5 | |
| 5 | 55-4414 | WASHER - spl (0.281) | 5 | |
| 6 | 92-5974 | INSULATION - evap | 1 | |
| 7 | 92-5976 | INSULATION - evap | 1 | |
| 8 | 55-558 | CLAMP - bulb | 1 | |
| 9 | 92-5975 | BRACKET - distributor | 1 | |
| 55-2957 | SCREW - bracket | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 10 | 61-3766 | VALVE - expansion | 1 | |
| 11 | 61-4753 | TUBE - liquid | 1 | |
| 12 | 55-9699 | ADAPTER - bulkhead (#12) | 1 | |
| 13 | 61-3798 | TUBE - suction | 1 | |
| 14 | 55-6570 | ADAPTER - bulkhead (#24) | 1 | |
| 15 | 61-3799 | TUBE - equalizer | 1 | |
| 16 | 55-6544 | CLAMP - tube | 1 | |
| 17 | 55-5294 | CLAMP (0.187 dia) | 1 | |
| 55-2979 | SCREW - clamp | 1 | ||
| 55-1800 | LOCKWASHER | 1 | ||
| 55-2086 | FLATWASHER | 1 | ||
| 18 | 41-4157 | SENSOR - temperature | 1 | |
| 19 | 55-7054 | NUT - shoulder | 1 | |
| 20 | 55-7052 | SLEEVE | 1 | |
| 21 | 61-4754 | TUBE - liquid line | 1 | |
| 22 | 55-2299 | BUSHING | 1 | |
| 23 | 61-869 | VALVE - solenoid | 1 | |
| 24 | 66-7539 | TUBE | 1 | |
| 25 | 55-2182 | BUSHING | 1 | |
| 26 | 55-9699 | ADAPTER | 1 | |
| 27 | 33-2193 | O-RING (11/16 id) | 1 | |
| 28 | 92-7768 | BRACKET - liquid line solenoid | 1 | |
| 55-2957 | SCREW - bracket | 2 | ||
| 55-1800 | LOCKWASHER - bracket | 2 | ||
| 55-6812 | NUT - bulkhead (1-3/16-12) | 1 | ||
| 55-7199 | LOCKWASHER (1.21 id) | 1 |
