Установкa Thermo King CT-15 схема CT-15 REFERENCE SHEET – 14U59
Обновление от: 10/20/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 901252 | CT-15 2 ZONE 24V 380V | 07/09 | ||
| 901253 | CT-15 2 ZONE 12V 115V | 07/09 | ||
| 901282 | CT-15 3 ZONE 24V 220V | 10/11 | ||
| 901283 | CT-15 2 ZONE 24V 220V | 07/09 | ||
| 900844 | CT-15 24V 3 ZONE 380V SYSTEM | 07/09 | ||
| 900845 | CT-15 3 ZONE 12V 115V | 07/09 | ||
| 700085 | KIT EVAP ST-CR 100 (S-2) 30 24V | 07/09 | ||
| 700086 | KIT EVAP ST-CR 200 (S-3) 30 24V | 07/09 | ||
| 700088 | KIT EVAP ST-CR 100 (S-2) 30 12V | 07/09 | ||
| 700089 | KIT EVAP ST-CR 200 (S-3) 30 12V | 07/09 | ||
| 700487 | KIT REMOTEBOX ST-CR | 10/11 | ||
| 701692 | KIT TANK CO2 430 LITER | 07/09 | ||
| 702208 | KIT HARNESS INTERCONNECT PARALLEL S-2 CT/S-3 CT | 10/11 | ||
| 719771 | KIT TANK CO2 330 LITER | 07/09 | ||
| 720420 | KIT REMOTEBOX THREADED COUPLINGS | 10/11 | ||
| 720421 | KIT SECOND TANK INSTALL | 10/11 | ||
| 800132 | KIT TANK MOUNTING BRACKETS V-TYPE 330L TANK | 10/11 | ||
| 800133 | KIT TANK MOUNTING BRACKETS HORIZONTAL 330L TANK | 10/11 | ||
| 800416 | KIT - INSTALLATION CT-15 3 ZONE 24V | 07/09 | ||
| 800417 | KIT - INSTALLATION CT-15 3 ZONE 12V | 07/09 | ||
| 800418 | KIT - INSTALLATION CT-15 2 ZONE 24V | 07/09 | ||
| 800419 | KIT - INSTALLATION CT-15 2 ZONE 12V | 07/09 | ||
| 800420 | KIT TANK CO2 MOUNTING BRACKETS US | 10/11 | ||
| 880177 | KIT HARDWARE ST-CR 100/200 (S-2/S-3) | 07/09 |
