Установкa Thermo King CT-10 SPECTRUM схема ELECTRICAL COMPONENTS (S-2 CT, ST-CR 200) – 189A6
Обновление от: 6/26/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 44-7354 | BOX - junction (For 50 model evaporators only) | 1 | |
| 55-3027 | SCREW - box | 2 | ||
| 55-2964 | LOCKWASHER | 6 | ||
| 55-2001 | FLATWASHER | 6 | ||
| 2 | 41-5686 | HARNESS - heaters (For 50 model evaporators only) | 1 | |
| 3 | 41-5687 | HARNESS - speed control | 1 | |
| 4 | 44-4551 | BOARD - terminal | 1 | |
| 55-3404 | SCREW - board | 2 | ||
| 55-2202 | LOCKWASHER | 2 | ||
| 55-2201 | FLATWASHER | 2 | ||
| 5 | 92-3293 | MARKSTRIP | 1 | |
| 6 | 99-3281 | MOUNT - cable tie | 7 | |
| 55-3628 | RIVET - mount | 7 | ||
| 7 | 41-2395 | VALVE - water (24V, see 189A5) | 1 | |
| 41-2394 | VALVE - water (12V, see 189A5) | 1 | ||
| 44-2789 | TERMINAL - ring (blue 1/4, 14-16 ga) | 2 | ||
| 41-125 | TERMINAL - splice | 2 | ||
| 8 | 61-2713 | VALVE - CO2 (24V, see 189A4) | 2 | |
| 61-2714 | VALVE - CO2 (12V, see 189A4) | 2 | ||
| 41-124 | TERMINAL - splice | 2 | ||
| 9 | 41-4445 | SENSOR - temperature | 1 | |
| 55-386 | WASHER | 1 | ||
| 10 | 78-1251 | HOUSING - blower | 1 | |
| 55-9761 | SCREW - housing | 3 | ||
| 33-3890 | FOAM - housing | 1 | ||
| 11 | 78-1252 | COVER - blower | 1 | |
| 12 | 78-1553 | BLOWER (24V) | 2 | |
| 78-1554 | BLOWER (12V) | 2 | ||
|
10-78-1362 | Вентилятор испарителя, Spectrum | 19 200 ₽ |
|
| 78-1712 | BLOWER (28V) | 1 | ||
| 10-78-1712 | Турбина испарителя, 24V, V-700/800 | 13 220 ₽ |
|
|
| 55-9694 | SCREW - blower | 8 | ||
| 13 | 41-2589 | SENSOR - return air | 1 | |
| 14 | 44-3918 | JUMPER - ground | 1 | |
| 55-6995 | FLATWASHER | 10 | ||
| 55-9762 | NUT & WASHER | 3 | ||
| 15 | 45-2408 | HEATER (For 50 model evaps only, w/ terminals, before 5/11) | 3 | |
| 45-2408 | HEATER (For 50 model evaps only, w/ wires, after 5/11) | 3 | ||
| 16 | 41-5688 | HEATER - drain tube (12V) | 2 | |
| 41-5685 | HEATER - drain tube (24V) | 2 | ||
| 44-2789 | TERMINAL - ring | 1 | ||
| 44-2788 | TERMINAL - fork | 1 | ||
| 17 | 61-1030 | CLAMP - heater (For 50 model evaporators only) | 6 | |
| 18 | 41-1514 | SWITCH - defrost termination | 1 | |
|
10-41-1514 | Датчик окончания оттайки | 14 220 ₽ |
|
| 55-7067 | SCREW - switch | 2 | ||
| 19 | 33-1217 | GROMMET - harness | 2 | |
| 20 | 33-3887 | GROMMET - fan to motor harness | 2 |
