Установкa Thermo King CT-10 & CT-15 SR-3 схема DOOR SWITCH – 269G2
Обновление от: 7/25/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 40-907 | KIT - door switch | 1 | |
| 51-1321 | SCREW - switch (0.75 in) | 2 | ||
| 55-8421 | SCREW - switch (1.0 in) | 2 | ||
| 55-2001 | FLATWASHER | 4 | ||
| 2 | 41-8361 | HARNESS - door switch | 1 | |
| 83-257 | GROMMET (3/8 id) | 1 | ||
| 41-125 | TERMINAL - splice | 4 | ||
| 3 | 92-4772 | NAMEPLATE - Door Switch | 1 |
