Установкa Thermo King CT-10 & CT-15 SR-3 схема FRAME & COVERS CT-15 – 269B2
Обновление от: 7/25/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 93-883 | FRAME | 1 | |
| 51-1896 | BOLT - mounting | 6 | ||
| 55-7347 | LOCKWASHER | 6 | ||
| 55-5186 | WASHER | 6 | ||
| 51-2507 | NUT | 6 | ||
| 2 | 93-892 | DOOR - bottom | 1 | |
| 3 | 93-893 | DOOR - middle | 1 | |
| 4 | 93-894 | DOOR - top | 1 | |
| 51-718 | SCREW - doors & skin | 22 | ||
| 5 | 91-9946 | NAMEPLATE - Thermo King | 1 | |
| 6 | 92-2434 | NAMEPLATE - TK Logo | 1 | |
| 7 | 92-7740 | NAMEPLATE - CT-15 | 1 | |
| 8 | 91-8342 | NAMEPLATE - TK Logo | 1 |
