Установкa Thermo King CSR 40SL-143 схема ELECTRICAL COMPONENTS (UNITS w/ 3 EVAP FANS) – 158F3
Обновление от: 6/25/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-2447 | SENSOR - head temperature | 1 | |
| 2 | 40-781 | CABLE - power | 1 | |
| 3 | 40-974 | KIT - sensor (supply air, return air & evap coil, graded) | 3 | |
|
40-974 OEM | Датчик температуры калиброванный | 8 770 ₽ |
|
|
10-40-974 | Датчик температуры калиброванный | 3 500 ₽ |
|
| 4 | 41-2503 | CABLE - power | 1 | |
| 5 | 41-1976 | PLUG - power (Minnekes) | 1 | |
| 44-9891 | TERMINAL - pin (cable end) | 3 | ||
| 44-6310 | TERMINAL - pin (plug end) | 4 | ||
| 6 | 66-3303 | VALVE - solenoid | 1 | |
| 7 | 60-328 | VALVE - solenoid | 1 | |
| 8 | 104-753 | MOTOR - condenser fan (see 155D4) | 1 | |
| 9 | 41-3116 | HARNESS - condenser | 1 | |
| 10 | 104-691 | MOTOR - evaporator (see 155E1) | 3 | |
| 11 | 41-3112 | HARNESS - evaporator & heaters | 1 | |
| 12 | 45-1791 | HEATER - evaporator | 6 | |
| 13 | 40-975 | SENSOR - temperature (condenser coil, ambient temp & optional humidity sensor) | 2 | |
|
40-975 OEM | Датчик температуры к-т, некалиброванный | 10 310 ₽ |
|
|
10-40-975 | Датчик температуры к-т, некалиброванный | 4 660 ₽ |
|
| 91-2197 | BRACKET - sensor | 2 | ||
| 14 | 66-7865 | VALVE - modulation (see 123A8) | 1 | |
| 15 | 91-8634 | BRACKET - heater | 1 | |
| 16 | 91-8629 | BRACKET - heater | 1 | |
| 17 | 91-8140 | SPRING - heater | 6 | |
| 18 | NSS | BOX - control (see 147B6) | 1 | |
| 19 | 41-530 | SWITCH - hpco (red bandwrap) | 1 | |
| 20 | 41-4523 | SWITCH - hpco (blue bandwrap) | 1 | |
|
41-4523 OEM | Выключатель высокого давления, SLX/SLXe | 15 650 ₽ |
|
| 10-41-4523 | Выключатель высокого давления, SLX/SLXe | 12 390 ₽ |
|
|
| 21 | 102-796 | COMPRESSOR - scroll | 1 | |
| 22 | 41-2517 | HARNESS - main (see 146D9) | 1 | |
| 23 | 60-327 | VALVE - solenoid | 1 | |
| 24 | 91-6988 | BRACKET - cable restraint | 1 | |
| 25 | 41-3401 | THERMOSTAT | 1 | |
| 55-9166 | SCREW - thermostat | 2 | ||
| 26 | 40-791 | SENSOR - defrost | 1 | |
| 40-791 OEM | Датчик оттайки | 8 070 ₽ |
|
