Установкa Thermo King CSR 40 схема HIGH VOLTAGE TRAY - HUMIDITY (OPTION 098036) – 149B1
Обновление от: 1/21/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-8662 | PANEL - high voltage | 1 | |
| 2 | 91-8147 | BRACKET - power module | 1 | |
| 55-7862 | SCREW - bracket | 3 | ||
| 55-7369 | LOCKWASHER | 4 | ||
| 55-7031 | LOCKWASHER (internal tooth) | 1 | ||
| 3 | 45-1806 | MODULE - power (see 145F1) | 1 | |
| 55-9195 | SCREW - module | 5 | ||
| 55-8987 | LOCKWASHER (internal tooth) | 5 | ||
| 55-8410 | FLATWASHER | 5 | ||
| 91-8415 | NAMEPLATE - fuses | 1 | ||
| 4 | 41-2129 | TRANSFORMER | 1 | |
| 55-7698 | LOCKWASHER | 4 | ||
| 55-7031 | FLATWASHER | 3 | ||
| 5 | 41-2208 | TAP - thermo bus | 1 | |
| 55-7367 | NUT | 5 | ||
| 55-7370 | LOCKWASHER | 7 | ||
| 6 | 41-2209 | TERMINATOR | 1 | |
| 7 | 91-8661 | BRACKET - emergency bypass | 1 | |
| 8 | 41-2210 | PC BOARD - emergency bypass | 1 | |
| 99-7849 | STRIP - gasket (25 ft) | A/R | ||
| 55-8723 | SCREW - bracket | 4 | ||
| 9 | 91-8538 | NAMEPLATE - emergency bypass | 1 | |
| 10 | 45-1853 | MODULE - mP-D output | 1 | |
| 11 | 41-2446 | CONTACTOR | 8 | |
| 12 | 44-8813 | INTERLOCK | 2 | |
| 13 | 41-2520 | SPACER - contactor | 2 | |
| 14 | 41-2401 | MODULE - current sense | 1 | |
| 15 | 41-2521 | BREAKER - circuit | 1 | |
| 16 | 91-8204 | RAIL - din | 1 | |
| 55-7862 | SCREW - rail | 6 | ||
| 55-7369 | LOCKWASHER | 2 | ||
| 55-7697 | FLATWASHER | 2 | ||
| 17 | 41-2690 | HARNESS - contactor | 1 | |
| 18 | 41-2319 | CONNECTOR - receptacle (12-pin) | 1 | |
| 19 | 99-6093 | MOUNT - cable tie | 2 | |
| 55-2864 | RIVET - mount | 2 | ||
| 55-2332 | BANDWRAP | 18 | ||
| 20 | 91-8737 | BLOCK - grounding | 4 | |
| 21 | 41-2689 | HARNESS - output module | 1 | |
| 22 | 41-2407 | PLUG (35-pin) | 1 | |
| 23 | 41-2493 | PLUG (12 socket) | 1 | |
| 24 | 41-2492 | CONNECTOR - receptacle (16-pin) | 1 | |
| 25 | 41-2249 | PLUG (3 socket) | 1 | |
| 26 | 41-2689 | HARNESS - output module | 1 | |
| 27 | 41-2495 | CONNECTOR - plug (6 socket) | 1 | |
| 41-2494 | CONNECTOR - receptacle (6-pin) | 1 | ||
| 28 | 99-7834 | NAMEPLATE - Caution | 1 |
