Установкa Thermo King CRR 20-37 & CRR 40-49, 109 Slimline for Hamburg-Sud схема ELECTRICAL COMPONENTS – 146D5
Обновление от: 7/31/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-8098 | RETAINER - sensor (K28-51579-00) | 1 | |
| 2 | 91-8728 | COVER (060-83031-02) | 1 | |
| 506-964 | CAP (for retainer kit) (K28-51580-00) | 1 | ||
| 33-2960 | GASKET - probe holder (K25-51595-11) | 1 | ||
| 3 | 504-244 | PROBE - condenser (360-53160-44) | 1 | |
| 4 | 41-2213 | CABLE - power (complete) | 1 | |
| 504-112 | CABLE - power | 1 | ||
| 41-2471 | TERMINAL - spade | 4 | ||
| 41-1976 | PLUG - electrical | 1 | ||
| 5 | 41-4300 | PROBE - compressor (360-53160-49) | 1 | |
| 6 | 40-791 | KIT - sensor (universal) (360-53160-43) | 1 | |
| 40-791 OEM | Датчик оттайки | 8 070 ₽ |
|
|
| 7 | 41-5460 | COIL - valve (24V 50/60 Hz) | 2 | |
| 8 | 104-753 | MOTOR - condenser fan (see 146D1) (K24-22021-00) | 1 | |
| 9 | 504-242 | WIRING - condenser fan (360-53160-42) | 1 | |
| 10 | 104-691 | MOTOR - evaporator fan (see 146D2) (K24-21354-00) | 3 | |
| 11 | 41-3401 | SWITCH - defrost termination (K25-19557-00) | 1 | |
| 12 | 45-1791 | HEATER (K25-51590-00) | 6 | |
| 13 | 40-791 | KIT - sensor (universal) (360-50957-00) | 1 | |
| 40-791 OEM | Датчик оттайки | 8 070 ₽ |
|
|
| 14 | 40-791 | KIT - sensor (universal) (360-50958-00) | 1 | |
| 40-791 OEM | Датчик оттайки | 8 070 ₽ |
|
|
| 15 | 509-1763 | BRACKET - heater (CRR 20) (060-83121-00) | 1 | |
| 91-8634 | BRACKET - heater (CRR 40) | 1 | ||
| 16 | 509-1767 | BRACKET - heater (CRR 20) (060-83120-00) | 2 | |
| 91-8629 | BRACKET - heater (CRR 40) | 2 | ||
| 55-8891 | SCREW - bracket | 11 | ||
| 17 | 502-251 | COMPRESSOR (see 146F2, CRR 20) (K15-70333-00) | 1 | |
| 18 | NSS | BOX - control (see 146D6) | 1 | |
| 55-7172 | SCREW - control box | 4 | ||
| 55-6995 | WASHER (K21-50411-06) | 4 | ||
| 55-9054 | WASHER (nylon) | 4 | ||
| 19 | 40-791 | KIT - sensor (universal) (360-53039-00) | 1 | |
| 40-791 OEM | Датчик оттайки | 8 070 ₽ |
|
|
| 20 | 91-8140 | SPRING - heater (K29-58815-01) | 6 | |
| 21 | 504-980 | KVQ 28 ACTUATOR (see 146E6) (K25-72045-00) | 1 |
