Установкa Thermo King CITI-RT Split схема CITI-RT SPLIT REFERENCE SHEET – 9U1
Обновление от: 10/9/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 918667 | System - Citi-RT Split 1000, R134a | 11/03 | ||
| 918668 | System - Citi-RT Split 1004, R134a | 11/03 | ||
| 918884 | System - Citi-RT Split 1000, R134a - Short Unit | 11/03 | ||
| 918885 | System - Citi-RT Split 1004, R134a - Short Unit | 11/03 | ||
| 919360 | System - Citi-RT Split 1000, Right Side Refrigeration Connection, R134a | 7/07 | ||
| 919361 | System - Citi-RT Split 1004, Right Side Refrigeration Connection, R134a | 7/07 | ||
| 920036 | System - Citi-RT Narrow Split 1000, R134a | 7/07 | ||
| 920037 | System - Citi-RT Narrow Split 1004, R134a | 7/07 | ||
| 099313 | Citi-RT Split Condenser/Evaporator | 11/03 | ||
| 099314 | Citi-RT Split Condenser/Evaporator/Heat | 11/03 | ||
| 099585 | Citi-RT Split Condenser/Evaporator - Short Unit | 11/03 | ||
| 099586 | Citi-RT Split Condenser/Evaporator/Heat - Short Unit | 11/03 | ||
| 099665 | Citi-RT Split Condenser/Evaporator - Side Refrigeration Connection | 7/07 | ||
| 099666 | Citi-RT Split Condenser/Evaporator/Heat - Side Refrigeration Connection | 7/07 | ||
| 006028 | Citi-RT Narrow Split Condenser/Evaporator | 7/07 | ||
| 006029 | Citi-RT Narrow Split Condenser/Evaporator/Heat | 7/07 | ||
| 099659 | ClimaAIRE I Control System Split | 11/03 | ||
| 719360 | ClimaAIRE I DP w/Harness (Unit to Driver Panel - 18.3 m length) | 11/03 | ||
| 718884 | Kit - Harness to Compressor (10 m) | 11/03 | ||
| 700522 | Kit - Harness to Compressor (10 m) | 7/07 | ||
| 006559 | ClimaAIRE II Control System Split 1000/1004 - Control Panel, Brush Fans, Brush Blowers | 11/03 | ||
| 700870 | Kit - ClimaAIRE I D w/Harness (18 m) | 7/07 | ||
| 720193 | ClimaAIRE II DP w/Harness (Unit to Driver Panel - 12 m length) | 11/03 | ||
| 720576 | ClimaAIRE II DP w/Harness (Unit to Driver Panel - 8 m length) | 11/03 | ||
| 720194 | Harness (Split Unit - 2 x Compressors - 18 m length) | 11/03 | ||
| 720195 | Harness (Split Unit - 2 x Compressors - 12 m length) | 11/03 | ||
| 720577 | Harness (Split Unit - 2 x Compressors - 8.2 m length) | 11/03 | ||
| 099660 | IntelligAIRE I Control System Split | 11/03 | ||
| 099279 | Eprom w/o Diagnostic for IntelligAIRE I | 11/03 | ||
| 099280 | Eprom w/o Diagnostic for IntelligAIRE I | 11/03 | ||
| 719361 | IntelligAIRE I DP w/Harness (Unit to Driver Panel - 18.3 m length) | 11/03 | ||
| 007075 | Kit - Fresh Air Damper (Electric) | 7/07 | ||
| 099309 | NO Fresh Air Damper | 11/03 | ||
| 006534 | Tube Heating System w/ Heat Valve | 11/03 | ||
| 006535 | Tube Heating System w/o Heat Valve | 11/03 | ||
| 819360 | Installation Kit - Citi-RT Split 1000/1004 | 11/03 | ||
| 818884 | Installation Kit - Citi-RT Split 1000/1004 - Bredam | 11/03 | ||
| 819361 | Installation Kit - Citi-RT Split 1000/1004 w/ Service Valves, Hose Installation | 7/07 | ||
| 718664 | Compressors 2 x TM31, 2B Pulley 24 V | 11/03 | ||
| 718885 | Compressors 2 x TM31, 8K Pulley 24 V | 11/03 | ||
| 720264 | Water Valve Kit - 27 VDC w/ Adapters | 11/03 | ||
| 720450 | Harness Kit (Unit to Water Solenoid Valve - 10 m length) | 11/03 | ||
| 720451 | Harness Kit (Unit to Water Solenoid Valve - 20 m length) | 11/03 | ||
| 700129 | Water Valve Kit - 2-way | 7/07 | ||
| 700130 | Water Valve Kit - 3-way | 7/07 | ||
| 700127 | Harness Kit - Servomotor Water Valve (10 m) | 7/07 | ||
| 700128 | Harness Kit - Servomotor Water Valve (20 m) | 7/07 | ||
| 718665 | Water Boost Pump Kit - 27 VDC, Hose Connections - 38 mm id, 5000 l/Hr | 11/03 | ||
| 719006 | Harness (Unit to Water Boost Pump - 14 m length) | 7/07 | ||
| 719007 | Harness (Unit to Water Boost Pump - 9 m length) | 7/07 | ||
| 719008 | Harness (Unit to Water Boost Pump - 7.6 m length) | 7/07 | ||
| 714765 | Air Filter Grille Kit | 11/03 | ||
| 715089 | Return Air Grill Kit - Black Color | 11/03 | ||
| 718670 | Hose Kit (FC 558 #12, #16 - 1m & Fittings) | 11/03 | ||
| 718881 | Hose Kit (FC 558 #12 - 8 + 10 m, #16 - 7 + 9 m & Fittings) | 11/03 | ||
| 718828 | Hoses Kit - Newclima (#12 - 15 m, #16 - 15 m, 90 deg / 90 deg Fittings) | 11/03 | ||
| 700286 | Hose Kit(#16, #12 - 15 m, 45 deg Fittings) | 7/07 | ||
| 709797 | Alternator Kit - 150 A, 24 VDC, 24 V Excitation, 3.25 inch | 11/03 | ||
| 711180 | Alternator Kit - 125 A, 24 VDC, 12 V Excitation, 3.25 inch | 11/03 | ||
| 715546 | Harness Extension Kit (6.35 m to Compressor) | 11/03 |
