Установкa Thermo King CITI-RT 1000 схема INSTALLATION COMPONENTS – 211C8
Обновление от: 4/24/10
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 66-1273 | VALVE - drain | 4 | |
| 2 | 91-9006 | HOSE | A/R | |
| 3 | 55-6726 | CLAMP | 8 | |
| 4 | 55-2330 | BANDWRAP (1.75 dia) | A/R | |
| 5 | 203-391 | SEALER - tape | A/R | |
| 6 | 203-505 | OIL - compressor (2 oz bottle) | 1 | |
| 7 | 55-8542 | WASHER - special | 6 | |
| 8 | 33-3191 | GASKET - flange | 2 | |
| 9 | 33-3706 | STRIP - neoprene (0.76 thk) | A/R | |
| 33-3531 | STRIP - neoprene (0.38 thk) | A/R | ||
| 99-9251 | STRIP - neoprene (0.62 thk) | A/R | ||
| 10 | 55-5886 | ADAPTER (#16) | 1 | |
| 11 | 55-5887 | ADAPTER (#20) | 1 | |
| 12 | 61-2802 | FITTING (manuli, #16, 45 deg) | 1 | |
| 51-584 | FITTING (manuli, #16, 45 deg) | 1 | ||
| 13 | 61-2803 | FITTING (manuli, #20, 45 deg) | 1 | |
| 51-581 | FITTING (manuli, #20, 45 deg) | 1 | ||
| 14 | 92-459 | FILTER - air | 1 | |
| 15 | 33-3166 | O-RING (#20) | 1 | |
| 16 | 33-3165 | O-RING (#16) | 1 | |
| 17 | 33-3707 | O-RING (2.125 id) | 1 | |
| 18 | 33-230 | O-RING (1.875 id) | 1 | |
|
10-33-230 | О-ринг сервисного клапана, X418/426/430/640 | 380 ₽ |
|
| PP-33-230 | О-ринг сервисного клапана, X418/426/430/640 | 220 ₽ |
|
|
| 19 | 51-1493 | INSERT | 1 |
