Установкa Thermo King CITADIS 26 kW ROTTERDAM схема FAN – 234H9
Обновление от: 4/7/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-8309 | PLATE - fan, weldment | 1 | |
| 55-6994 | SCREW - fan assy to unit frame | 8 | ||
| 55-9190 | LOCKWASHER | 8 | ||
| 55-7373 | NUT - captive | 4 | ||
| 55-9837 | NUT - captive | 4 | ||
| 2 | 92-7802 | GRILLE | 1 | |
| 55-8464 | SCREW - grille to fan plate | 4 | ||
| 51-124 | SCREW - fan to grille | 4 | ||
| 55-9190 | LOCKWASHER | 8 | ||
| 55-8893 | FLATWASHER | 8 | ||
| 55-7373 | NUT - captive | 4 | ||
| 3 | 92-7714 | CYLINDER FAN | 4 | |
| 5 | 78-1756 | FAN - service set (connector included) | 1 | |
| 6 | 92-7803 | HOLDER | 1 | |
| 55-6994 | SCREW - holder | 2 | ||
| 55-9190 | LOCKWASHER | 2 | ||
| 55-7373 | NUT - captive | 2 | ||
| 7 | 51-1669 | CLIP - plastic | 2 | |
| 8 | 99-3281 | MOUNT - bandwrap | 3 | |
| 51-2030 | RIVET - mount | 3 | ||
| 56-2330 | BANDWRAP | 3 | ||
| 9 | 92-3279 | RUBBER - profile | A/R | |
| 10 | 33-4516 | STRIP - neoprene | A/R |
