Установкa Thermo King CG-II M22, M22D, M22E схема AIR INTAKE & EXHAUST GROUP – 120A6
Обновление от: 11/25/09
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 13-664 | CLEANER - air | 1 | |
| 2 | 99-1400 | CLAMP - oil cup | 1 | |
| 3 | 11-2610 | CUP - air cleaner | 1 | |
| 4 | 11-2457 | CLAMP | 1 | |
| 55-3048 | SCREW - clamp | 2 | ||
| 55-2641 | FLATWASHER | 2 | ||
| 55-4955 | NUT | 2 | ||
| 5 | 55-3991 | CLAMP - hose | 2 | |
| 6 | 11-8056 | HOSE - air cleaner | 1 | |
| 7 | 11-5364 | ELBOW - air intake | 1 | |
| 55-5022 | SCREW - elbow | 2 | ||
| 55-4613 | FLATWASHER | 2 | ||
| 55-2959 | LOCKWASHER | 2 | ||
| 8 | 55-2332 | BANDWRAP | 2 | |
| 9 | 11-8057 | HOSE - breather | 1 | |
| 10 | 33-487 | GASKET - elbow | 1 | |
|
10-33-487 | Прокладка термостата, Isuzu 2.2, SB-I/II/III / SMX/SMX-II | 910 ₽ |
|
| 11 | 55-1592 | CONNECTOR - hose (restricted) | 1 | |
| 12 | 55-139 | SCREW - muffler | 2 | |
| 13 | 55-371 | FLATWASHER | 2 | |
| 14 | 33-2314 | GASKET - exhaust | 1 | |
| 33-2314 OEM | Прокладка глушителя, Isuzu 2.2 DI (D201), Yanmar 482 / 486 / 486V | 1 250 ₽ |
|
|
|
10-33-2314 | Прокладка глушителя, Isuzu 2.2 DI (D201), Yanmar 482 / 486 / 486V | 990 ₽ |
|
|
PP-33-2314 | Прокладка глушителя, Isuzu 2.2 DI (D201), Yanmar 482 / 486 / 486V | 480 ₽ |
|
| 15 | 55-790 | LOCKWASHER | 2 | |
| 16 | 55-312 | NUT | 2 | |
| 17 | 12-654 | MUFFLER (steel, see note) | 1 | |
| 12-654 | MUFFLER (stainless steel) | 1 | ||
| 18 | 55-5695 | SCREW - muffler | 2 | |
| 19 | 55-5411 | LOCKWASHER | 2 | |
| 55-402 | FLATWASHER | 2 |
