Установкa Thermo King CF-III M9, M9A, M9B & M9C Prepared for Hapag Lloyd схема CONTROL BOX (M9) – 95F13
Обновление от: 1/11/99
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-3860 | BOX - control | 1 | |
| 55-2977 | SCREW - box | 4 | ||
| 55-2086 | FLATWASHER | 4 | ||
| 55-1800 | LOCKWASHER | 4 | ||
| 2 | 44-6822 | SOCKET - remote monitor | 1 | |
| 204-209 | LEAD - thermistor | 1 | ||
| 55-4437 | SCREW - socket | 4 | ||
| 55-2359 | FLATWASHER | 8 | ||
| 55-2360 | LOCKWASHER | 4 | ||
| 55-2361 | NUT | 4 | ||
| 3 | 44-9111 | RELAY | 3 | |
|
10-44-9111 | Реле | 1 310 ₽ |
|
| 4 | 44-5537 | SOCKET - relay | 3 | |
| 5 | 44-6560 | SWITCH - on/off (4pdt) | 1 | |
| 6 | 44-2099 | SWITCH - defrost (1p) | 1 | |
| 44-739 | BOOT - switch | 2 | ||
| 7 | 99-8981 | ANGLE | 1 | |
| 55-1587 | SCREW - angle | 2 | ||
| 55-3028 | WASHER - sealing | 2 | ||
| 55-4953 | NUT | 2 | ||
| 8 | 99-8149 | LATCH - door | 1 | |
| 9 | 55-4953 | NUT | 1 | |
| 55-2086 | FLATWASHER | 3 | ||
| 55-2363 | LOCKWASHER | 1 | ||
| 10 | 99-8994 | SPACER - tube | 1 | |
| 11 | 99-8993 | BRACKET - latch | 1 | |
| 12 | 55-2957 | SCREW | 1 | |
| 13 | 99-9240 | ANGLE - microcontroller | 1 | |
| 55-3059 | NUT - captive | 3 | ||
| 55-2991 | SCREW - angle | 2 | ||
| 55-3008 | WASHER - sealing | 2 | ||
| 55-2001 | FLATWASHER | 2 | ||
| 55-4560 | NUT | 2 | ||
| 14 | 55-4953 | NUT | 1 | |
| 15 | 99-8162 | ROLLER - door latch | 1 | |
| 99-8151 | SPACER | 1 | ||
| 16 | 55-2086 | FLATWASHER | 1 | |
| 17 | 55-2977 | SCREW - roller | 1 | |
| 18 | 99-8164 | WINDOW | 1 | |
| 19 | 91-230 | NAMEPLATE - On/Off Defrost | 1 | |
| 20 | 91-1263 | COVER - control box | 1 | |
| 21 | 99-8986 | STRIP - gasket (25 ft) | A/R | |
| 22 | 99-7900 | ROD - cover | 2 | |
| 55-3473 | PIN | 2 | ||
| 23 | 44-7594 | BOARD - pc/LED | 1 | |
| 91-2453 | NAMEPLATE - Light Mode Indicator | 1 | ||
| 91-231 | PLATE - spacer | 1 | ||
| 55-3696 | SCREW - board | 1 | ||
| 55-3443 | SCREW - board | 2 | ||
| 55-3023 | WASHER - sealing | 2 | ||
| 24 | 99-8161 | SHIELD - light | 2 | |
| 55-3099 | SCREW - shield | 8 | ||
| 55-3008 | WASHER - sealing | 8 | ||
| 55-2001 | FLATWASHER | 8 | ||
| 55-4560 | NUT | 8 | ||
| 25 | 99-9401 | NAMEPLATE - Lights Display | 1 | |
| 26 | 33-2749 | BUSHING - cable/plug | 1 | |
| 27 | 45-1320 | CABLE - power (yellow, 69 ft) | 1 | |
| 28 | 44-4051 | PLUG - power (MIPCO, 460V) | 1 | |
| 41-1976 | PLUG - power (Minnekes) | 1 | ||
| 41-2820 | PLUG - power (ESL) | 1 | ||
| 44-9891 | TERMINAL - pin (cable end) | 3 | ||
| 44-6310 | TERMINAL - pin (plug end) | 4 | ||
| 29 | 91-3238 | CLAMP - cable | 1 | |
| 55-2977 | SCREW - clamp | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 55-1800 | LOCKWASHER | 2 | ||
| 30 | 91-3238 | BRACKET - emergency bypass | 1 | |
| 55-4953 | NUT - bracket (hexstop) | 2 | ||
| 55-2086 | FLATWASHER | 2 | ||
| 31 | 91-2477 | NAMEPLATE - emergency bypass | 1 | |
| 32 | 44-2101 | SWITCH - emergency bypass | 2 | |
| 33 | 91-499 | ROD - gang | 1 | |
| 55-5202 | SCREW - set (gang rod) | 2 | ||
| 34 | 44-6812 | RESISTOR (10 ohm) | 1 | |
| 55-5353 | SCREW - resistor | 1 | ||
| 55-3693 | WASHER (fiber) | 1 | ||
| 55-2359 | FLATWASHER | 2 | ||
| 55-2361 | NUT | 1 |
