Установкa Thermo King CF-II M1C схема NAMEPLATES – 83F4
Обновление от: 7/15/98
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 99-4383 | NAMEPLATE - Caution Fan | 5 | |
| 2 | 99-7105 | NAMEPLATE - blower removal | 2 | |
| 99-7104 | NAMEPLATE - Thermo King | 1 | ||
| 4 | 91-582 | NAMEPLATE - Light Box Mode | 1 | |
| 5 | 99-9601 | NAMEPLATE - liquid level (R12) | 1 | |
| 6 | 99-7450 | NAMEPLATE - Load Capacity | 1 | |
| 7 | 91-8755 | NAMEPLATE - Temperature Conversion | 1 | |
| 8 | 91-583 | BRACKET - nameplate | 1 | |
| 91-584 | NAMEPLATE - Operating Instructions (English/Spanish) | 1 | ||
| 91-585 | NAMEPLATE - Operating Instructions (Spanish/Chinese) | 1 | ||
| 91-586 | NAMEPLATE - Operating Instructions (Chinese/Japanese) | 1 | ||
| 91-587 | NAMEPLATE - Operating Instructions (Jap/Jap) | 1 | ||
| 91-588 | NAMEPLATE - Wiring/Schematic | 1 | ||
| 91-589 | NAMEPLATE - Wiring | 1 | ||
| 9 | 99-9084 | NAMEPLATE - arrow | 1 | |
| 10 | 91-6141 | NAMEPLATE - Caution Fan | 1 | |
| 11 | 99-6783 | NAMEPLATE - arrow | 1 | |
| 12 | 99-6784 | NAMEPLATE - Fresh Air Exchange Rate | 1 |
