Установкa Thermo King CB-III схема INSTALLATION COMPONENTS – 83A3
Обновление от: 5/29/01
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 91-408 | BOX - cab control (see 83A11) | 1 | |
| 2 | 44-7646 | HARNESS - box cab & engine | 1 | |
| 3 | 20-176 | KIT - compressor w/valves (See 114F11) | 1 | |
| 4 | 44-6146 | BREAKER - circuit (12V, 40 amp) | 1 | |
|
10-44-6146 | Автоматический выключатель, 40A | 2 220 ₽ |
|
| 44-6145 | BREAKER - circuit (24V, 20 amp) | 1 | ||
|
30-44-6145 | Предохранитель 20А | 1 320 ₽ |
|
| 5 | 44-4397 | SOLENOID (12V) | 1 | |
| 41-3987 | SOLENOID (24V) | 1 | ||
| 44-7663 | DIODE - silicone | 1 | ||
| 6 | 66-5015 | TUBE - equalizer | 1 | |
| 7 | 66-4609 | FITTING - swivel | 3 | |
| 8 | 44-6132 | SWITCH - lpco | 1 | |
| 33-768 | GASKET - flare | 1 | ||
| 9 | 66-4359 | FILTER - suction line | 1 | |
| 33-1837 | GASKET - flare | 2 | ||
| 10 | 67-944 | HOSE - liquid & defrost | A/R | |
| 11 | 67-944 | HOSE - suction | A/R | |
| 12 | 66-4868 | FITTING - liquid & defrost | 1 | |
| 13 | 66-4852 | FITTING - discharge | 1 | |
| 14 | 44-6864 | HARNESS - condenser | 1 | |
| 15 | 33-1216 | GROMMET | 1 | |
| 16 | 44-7666 | HARNESS - evaporator | 1 | |
| 17 | 11-3305 | SLEEVING - hose (defrost) | A/R | |
| 18 | 55-2686 | CLAMP - hose | 2 | |
| 19 | 55-2154 | CLAMP - hose (15/16 dia) | 8 | |
| 55-3598 | CLAMP - hose (1-11/64 id) | 8 | ||
| 55-5657 | SCREW - clamp | 16 | ||
| 20 | 44-7668 | HARNESS - evaporator | 1 | |
| 21 | 66-4861 | VIBRASORBER - discharge (see 83B11) | 1 | |
| 22 | 66-4851 | HOSE - discharge | 1 | |
| 23 | 204-677 | CUTTER - hose | 1 | |
| 204-678 | BLADE - replacement | 1 | ||
| 24 | 204-676 | CRIMPER - R12 hose | 1 | |
| 25 | 204-679 | FITTING - charging lines (w/ Schrader valve) | 1 |
