Установкa Thermo King CB-I схема STRUCTURAL ELECTRICAL COMPONENTS - EVAPORATOR – 58G5
Обновление от: 2/6/97
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 98-2464 | HOUSING - evaporator | 1 | |
| 2 | 44-6140 | HARNESS - evaporator | 1 | |
| 3 | 44-6519 | CONNECTOR (2-pin) | 1 | |
| 4 | 99-6093 | MOUNT - cable tie | 6 | |
| 55-2332 | BANDWRAP | A/R | ||
| 5 | 44-3475 | SWITCH - pressure differential | 1 | |
| 99-1143 | HOSE (plastic, cut to 20) | 1 | ||
| 99-1275 | PROBE - pressure switch | 1 | ||
| 10-99-1275 | Зонд | 800 ₽ |
|
|
| 55-3136 | RIVET - probe | 1 | ||
| 6 | 99-7041 | MOUNT - motor | 2 | |
| 7 | 99-7046 | ORIFICE | 1 | |
| 8 | 44-8526 | MOTOR - evaporator fan (12V) | 1 | |
|
10-44-8526 | Электромотор вентилятора 12V | 29 070 ₽ |
|
| 44-6969 | MOTOR - evaporator fan (24V) | 1 | ||
| 9 | 78-612 | FAN - evaporator | 1 | |
| 10 | 99-7040 | PANEL - access | 1 | |
| 11 | 98-2649 | GUARD - evaporator | 2 | |
| 55-2963 | SCREW - guard | 4 | ||
| 55-4954 | LOCKNUT | 4 | ||
| 12 | 99-7043 | CLAMP - defrost tube | 3 | |
| 13 | 44-3155 | SWITCH - defrost termination | 1 | |
|
10-44-3155 | Выключатель оттайки, KD/MD/RD-I / SB-I/II | 4 780 ₽ |
|
| 14 | 44-6369 | THERMOSTAT (F) | 1 | |
| 44-6868 | THERMOSTAT (C) | 1 | ||
| 55-3513 | SCREW - thermostat | 5 | ||
| 99-7044 | BRACKET - thermostat | 1 | ||
| 55-2270 | RIVET - bracket | 6 | ||
| 15 | 99-7045 | BRACKET - valve | 1 | |
| 99-1853 | U-BOLT | 1 | ||
| 16 | 99-7042 | GUARD - evaporator fan | 1 | |
| 17 | 55-1587 | SCREW | 4 | |
| 55-4953 | LOCKNUT | 4 | ||
| 18 | 55-1587 | SCREW - panel | 12 | |
| 55-3059 | NUT - captive | 12 |
