Установкa Thermo King C-100/200/300 схема COMPRESSOR & HOSE GROUP (C-100) – 197D3
Обновление от: 8/31/13
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | NSS | COMPRESSOR - TM08-HD (see 250E5) | 1 | |
| 2 | NSS | CLUTCH (see 250E5) | 1 | |
| 203-515 | OIL - compressor (ester base, 1 liter) | A/R | ||
| 203-505 | OIL - compressor (ester base, 8 oz) | A/R | ||
| 3 | 51-2469 | FITTING - suction (90 deg, #10, see 165D6) | 1 | |
| 4 | 33-672 | O-RING - suction | 1 | |
|
10-33-672 | Прокладка компрессора Regulator | 410 ₽ |
|
| 33-672 OEM | Прокладка компрессора Regulator | 80 ₽ |
|
|
| 5 | 51-2432 | FITTING - discharge (90 deg, #8, see 165D6) | 1 | |
| 6 | 33-2350 | O-RING - discharge | 1 | |
| 7 | 67-1710 | HOSE - refrigeration (#10) | A/R | |
| 8 | 67-1709 | HOSE - refrigeration (#8) | A/R | |
| 9 | 67-1782 | HOSE - refrigeration (#4) | A/R | |
| 10 | 51-2437 | FITTING - liquid (90 deg, #4) | 2 | |
| 11 | 33-1461 | O-RING - liquid (#4, 5/16 id) | 2 | |
| 12 | 33-566 | O-RING - discharge (#8, 1/2 id) | 1 | |
| 13 | 51-2441 | FITTING - discharge (straight, #8) | 1 | |
| 14 | 33-2115 | O-RING - suction (#10, 5/8 id) | 1 | |
| 15 | 51-2448 | FITTING - suction (90 deg, #10) | 1 | |
| 16 | 92-3841 | CLAMP - hose (18 mm) | 4 | |
| 91-6690 | CLAMP - hose (22 mm) | 4 | ||
| 92-3842 | CLAMP - hose (30 mm) | 2 | ||
| 17 | 92-3469 | HOSE - drain | 1 | |
| 18 | 55-9919 | SCREW - condenser | 4 | |
| 55-9499 | WASHER (w/ inclined face) | 4 | ||
| 55-9500 | WASHER (w/ compensator foot) | 4 | ||
| 51-793 | WASHER - special | 4 | ||
| 51-373 | WASHER - rubber | 4 | ||
| 55-8536 | FLATWASHER | 4 | ||
| 55-7344 | NUT | 4 | ||
| 19 | 55-7172 | SCREW - evaporator | 4 | |
| 55-8893 | WASHER (fender) | 8 | ||
| 55-7042 | NUT | 4 | ||
| 20 | 33-1216 | GROMMET - hoses | 1 | |
| 21 | 20-193 | KIT - swivel manifold (incl manifold bracket & screw) | 1 | |
| 22 | 51-1652 | SCREW - bracket | 1 | |
| 23 | 33-2882 | O-RING - manifold to compressor | 2 |
