Установкa Thermo King Bus Drive Kits схема DRIVE KIT 701193 - MAN 12.240, TM31 – 227F3
Обновление от: 2/6/08
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 108-2567 | PLATE - front | 1 | |
| 2 | 108-2568 | BOLT - plate | 2 | |
| 3 | 108-2569 | SPACER | 1 | |
| 4 | 55-7072 | FLATWASHER | 5 | |
| 5 | 51-1086 | NUT | 1 | |
| 6 | 108-2570 | REINFORCEMENT - assembly | 1 | |
| 7 | 108-2571 | BOLT (M10) | 2 | |
| 8 | 108-2572 | BRACKET - assembly, compressor | 1 | |
| 9 | 51-239 | BOLT | 11 | |
| 10 | 77-2808 | PULLEY - complete | 1 | |
| 108-1583 | PULLEY | 1 | ||
| 108-2229 | BEARING | 1 | ||
| 55-7437 | RING - retain | 1 | ||
| 11 | 108-1834 | SCREW - pulley | 1 | |
| 12 | 108-1714 | LOCKWASHER | 1 | |
| 13 | 92-4366 | SPACER | 1 | |
| 14 | 92-4365 | INSERT | 1 | |
| 15 | 92-4367 | ROD - tension | 1 | |
| 16 | 55-7069 | FLATWASHER | 1 | |
| 17 | 55-7727 | LOCKWASHER | 1 | |
| 18 | 55-4621 | NUT | 2 | |
| 19 | 108-2573 | PULLEY | 1 | |
| 20 | 108-2574 | BOLT - pulley | 6 | |
| 21 | 78-1379 | BELT | 1 |
