Установкa Thermo King Bus Drive Kits схема DRIVE KIT 701072 - EURORIDER 367 E.12.43 – 224D8
Обновление от: 8/13/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 108-2448 | SUPPORT | 1 | |
| 2 | 108-2233 | BASE - assembly | 1 | |
| 3 | 51-140 | SCREW - base to support | 4 | |
| 4 | 55-5914 | FLATWASHER | 15 | |
| 5 | 51-143 | NUT | 12 | |
| 6 | 92-4356 | SUPPORT | 1 | |
| 7 | 55-4723 | SCREW - support to base | 4 | |
| 8 | 51-145 | WASHER | 4 | |
| 9 | 108-1986 | PLATE - threaded | 2 | |
| 10 | 108-1817 | SCREW - tension | 1 | |
| 11 | 55-9871 | NUT | 2 | |
| 12 | 92-3058 | SILENTBLOCK | 4 | |
| 13 | 55-7003 | NUT - silentblock | 2 | |
| 14 | 108-1746 | FLATWASHER | 3 | |
| 15 | 92-4341 | SUPPORT - compressor | 2 | |
| 16 | 108-1745 | SCREW - compressor | 4 | |
| 17 | 55-399 | WASHER | 4 | |
| 18 | 92-4344 | STRAP - ground | 1 | |
| 19 | 108-2234 | PULLEY | 1 | |
| 20 | 108-2235 | BELT | 1 |
