Установкa Thermo King Bus Drive Kits схема DRIVE KIT 700230 - VOLVO B12MA EURO 3, 2xTM31 – 219B7
Обновление от: 1/31/07
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 108-2426 | WALL - floor assy | 1 | |
| 2 | 108-2427 | WALL - front assy | 1 | |
| 3 | 108-2428 | WALL - rear assy | 1 | |
| 4 | 108-2429 | WALL - side | 1 | |
| 5 | 108-2430 | WALL - slanted side | 1 | |
| 6 | 108-2358 | SCREW | 18 | |
| 7 | 51-233 | NUT | 4 | |
| 8 | 108-1705 | SCREW | 2 | |
| 9 | 55-7072 | FLATWASHER | 2 | |
| 10 | 55-6573 | NUT | 2 | |
| 11 | 108-2431 | SLIDER | 2 | |
| 12 | 108-2432 | SLIDER | 2 | |
| 13 | 55-5579 | SCREW | 8 | |
| 14 | 51-144 | WASHER | 12 | |
| 15 | 108-2433 | SCREW | 12 | |
| 16 | 108-2434 | SUPPORT | 1 | |
| 17 | 55-7004 | SCREW | 2 | |
| 18 | 108-2435 | PAD | 1 | |
| 19 | 55-8751 | SCREW | 2 | |
| 20 | 108-2436 | BELT | 2 |
