Установкa Thermo King Bus Accessories & Options схема CONVECTOR (1E46606G01) – 240E1
Обновление от: 9/9/11
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| NSS | CONVECTOR - TKV 800 (curbside rear) | 1 | ||
| 1 | 92-8083 | COVER (4 ft lg) | A/R | |
| 2 | 92-3057 | CAP - end piece | 1 | |
| 3 | 92-3431 | UNION | 1 | |
| 4 | NSS | HEATER - coil | 1 | |
| 5 | 61-1099 | VALVE - dearate | 1 | |
| 6 | 51-773 | RIVET - plastic | 2 | |
| 7 | 92-2649 | BRACKET - bottom | 2 | |
| 8 | 92-2650 | BRACKET - top | 2 | |
| 9 | 92-2647 | SLIDER | 2 | |
| 10 | 51-262 | CLAMP | 2 | |
| 11 | 92-7767 | BRACKET - fasting profile (4 ft) | A/R | |
| 12 | 92-8085 | BRACKET - wall | 1 | |
| 13 | 92-8086 | BRACKET - wall (end) | 1 | |
| 14 | 51-1227 | RIVET | 18 |
