Установкa Thermo King Bus A/C & Heating Components схема ELECTRICAL COMPONENTS - F3500S & F3500C (F35S & F35C, 718697) – 176H2
Обновление от: 4/9/04
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 41-3187 | MOTOR - damper (see 176H1) | 3 | |
| 2 | 78-1198 | BLOWER - evaporator | 1 | |
| 41-3200 | RESISTOR - speed control | 1 | ||
| 3 | 510-2259 | SUPPORT - blower | 2 | |
| 55-7372 | SCREW - holder | 2 | ||
| 55-9190 | LOCKWASHER | 2 | ||
| 4 | 92-2204 | BRACKET - blower | 1 | |
| 55-6994 | SCREW - bracket | 1 | ||
| 55-9190 | LOCKWASHER | 2 | ||
| 5 | 41-4844 | HARNESS - damper | 1 | |
| 6 | 44-8294 | CONNECTOR - shroud (6-pin) | 1 | |
| 7 | 41-4845 | CONNECTOR - damper | 3 | |
| 44-8539 | SOCKET - receptacle | 6 | ||
| 8 | 41-4843 | HARNESS - blower | 1 | |
| 9 | 44-7880 | CONNECTOR - shroud (4-pin) | 1 | |
| 10 | 41-4850 | TERMINAL - motor | 4 | |
| 11 | 33-428 | GROMMET - harness | 1 | |
| 12 | 41-3233 | HARNESS - main | 1 | |
| 13 | 44-7881 | CONNECTOR - tower (4-pin) | 2 | |
| 14 | 44-7872 | CONNECTOR - tower (6-pin) | 1 | |
| 15 | 41-3237 | CONNECTOR - water valve | 1 | |
| 41-3238 | TERMINAL - connector | 7 | ||
| 16 | 41-3234 | CONNECTOR - modules | 4 | |
| 41-3236 | TERMINAL - connector | A/R | ||
| 41-3240 | RESISTOR | 3 | ||
| 17 | 44-9569 | CONNECTOR - shroud (3-pin) | 1 | |
| 18 | 44-6959 | CONNECTOR - tower (3-pin) | 1 | |
| 19 | 44-7880 | CONNECTOR - shroud (4-pin) | 1 | |
| 20 | 41-3241 | HARNESS - ignition | 1 | |
| 21 | 44-7881 | CONNECTOR - tower (4-pin) | 1 | |
| 22 | 41-3567 | MODULE - control (water valve only) | 1 | |
| 23 | 41-3543 | MODULE - control (damper) | 3 | |
| 24 | 11-9237 | VALVE - water | 1 | |
| 25 | 45-2018 | PANEL - box front assembly (see 176H3) | 1 |
