Установкa Thermo King BE-550 схема CONTROL PANEL (12V w/ SKIRT MOUNT CONDENSER) – 258F7
Обновление от: 7/26/12
| № | TK # | Описание | Кол-во Цена | |
|---|---|---|---|---|
| 1 | 92-2510 | PANEL - control | 1 | |
| 2 | 41-4450 | BOARD - printed circuit | 1 | |
| 3 | 55-9624 | SPACER | 7 | |
| 4 | 55-7033 | FLATWASHER | 4 | |
| 5 | 55-7034 | NUT - board | 4 | |
| 6 | 41-895 | RELAY (1 pdt) | 8 | |
|
30-41-895 | Реле | 1 650 ₽ |
|
| 7 | 44-9758 | FUSE (10 amp) | 1 | |
|
10-44-9758 | Предохранитель 10 ампер 10 шт | 1 860 ₽ |
|
| 8 | 41-2978 | FUSE (20 amp) | 3 | |
| 30-41-2978 | Предохранитель 32V 20А | 500 ₽ |
|
|
| 9 | 44-9344 | FUSE (15 amp) | 5 | |
|
10-44-9344 | Предохранитель 15 ампер 10 шт | 1 860 ₽ |
|
| 10 | 51-254 | SPACER | 3 | |
| 11 | 92-2511 | COVER - panel | 1 | |
| 12 | 55-7826 | SCREW - cover | 3 | |
| 13 | 55-7404 | LOCKWASHER | 3 | |
| 14 | 55-7033 | FLATWASHER | 3 | |
| 15 | 92-2512 | STRIP - flange | 2 | |
| 16 | 92-1540 | STRIP - flange | 4 | |
| 17 | 92-9622 | NAMEPLATE - fuses | 1 | |
| 18 | 41-5078 | HARNESS - short circuit | 1 |
